£35.99

Stock Available: 0
  • Computer case Fan 12 cm 2000 RPM
  • 22.6 dB 2.34 mmH2O Self-Stabilising Oil-pressure Bearing (SSO)
  • Brown

The NF-A12x25 is a highly optimised next-generation 120mm fan that integrates Noctua’s latest innovations in aerodynamic engineering in order to achieve an unprecedented level of quiet cooling performance. It takes state-of-the-art technologies such as the AAO (Advanced Acoustic Optimisation) frame or Flow Acceleration Channels and combines them with a record tight tip clearance of only 0.5mm, which is made possible by using the novel Sterrox liquid-crystal polymer (LCP) compound as well as a metal-reinforced motor hub and axis for ultimate precision. Following the approach of Noctua’s A-series, the NF-A12x25 is a true all-rounder that yields superb results in all types of usage, regardless of whether it’s in low-impedance, airflow-oriented applications such as case cooling, or high-impedance, pressure-demanding scenarios such as on heatsinks and watercooling radiators. The 4-pin PWM version supports fully automatic speed control via PWM fan headers and comes with a Low-Noise Adaptor to reduce the maximum speed from 2000 to 1700rpm. Topped off with exceptional running smoothness, Noctua’s reference-class SSO2 bearing, a rich bundle of accessories and 6-year manufacturer’s warranty, the NF-A12x25 is a premium-quality product through and through. Its superior efficiency, cutting-edge construction and pioneering materials make it an elite choice for the most discerning demands.

Performance
Bearing type Self-Stabilising Oil-pressure Bearing (SSO)
Maximum air pressure 2.34 mmH2O
Minimum air pressure 1.65 mmH2O
Airflow with LNA (max) 84.5 m³/h
Airflow 102.1 m³/h
Noise level with LNA (max) 18.8 dB
Noise level (high speed) 22.6 dB
Rotational speed with LNA (max) 1700 RPM
Rotational speed (max) 2000 RPM
Rotational speed (min) 450 RPM
Compatible processor series Not supported
Supported processor sockets Not supported
Fan diameter 12 cm
Type Fan
Suitable location Computer case
Design
Fan connector 4-pin
Material Liquid Crystal Polymers (LCP)
Product colour Brown
Power
Maximum current 0.14 A
Voltage 12 V
Power consumption (typical) 1.68 W
Weight & dimensions
Height 120 mm
Depth 25 mm
Width 120 mm
Other features
Mean time to failure (MTTF) 150000 h
Logistics data
Harmonized System (HS) code 84733080
