£512.99

Stock Available: 0
  • Managed L2 Web-based management
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 8 Console port: RJ-45
  • 10G support 10GBASE-T, 100BASE-TX, 1000BASE-T
  • MAC address table: 32000 entries
  • Rack mounting

Industry’s First SMB Switch with 10-Gigabit Connectivity
NETGEAR is leading the networking industry with the market’s first cost-efficient 10-Gigabit Switch for small and medium businesses. The XS708E provides eight 10GE ports at a very affordable price compared to 10GE Enterprise switches in the marketplace. With the enormous growth of network traffic and network storage in recent years, 10GE is becoming a natural upgrade for many businesses in order to keep up with their network performance and business efficiency demands. This impacts not only the large enterprises, but for small and medium businesses as well since many SMBs are operating with big data even though the company size is small. NETGEAR recognizes the needs of a growing network for our SMB customers and has come up with the industry’s first cost-efficient 10GE solution.

The XS708E consists of eight 10GE copper ports and one combo 10GE Fiber SFP+ port. With 10GBASE-T, customers can use Cat6 or Cat7 copper cables with standard RJ45 Ethernet jacks that are already widely used in their current network. Network speeds can improve up to 10x going from traditional Gigabit to 10-Gigabit with minimal network changes and upgrades.

The XS708E belongs to the NETGEAR ProSAFE® Plus Switch Product family. On top of the plug-N-play 10-Gigabit Ethernet connectivity, it also offers some fundamental network features that will help optimize the performance of business networks such as VLAN, QoS, IGMP Snooping, Link Aggregation (LAG), rate limiting and traffic monitoring. ProSAFE® Plus Switches are an upgrade from Unmanaged Switches, delivering great value and exceptional performance.

The XS708E 10-Gigabit ProSAFE® Plus Switch from NETGEAR is the ideal switch for SMBs considering simple and affordable 10GE connectivity into their 10GE-capable servers and storage devices.

- 8 ports deliver up to 10Gbps of dedicated, non-blocking bandwidth per port
- Simple, yet useful network set-up on top of plug-and-play connectivity
- VLAN support for traffic segmentation
- Quality of Service (QoS) for traffic prioritization
- Auto “denial-of-service” (DoS) prevention
- Troubleshoot connection issues via cable test
- Loop prevention and broadcast storm controls
- IGMP snooping for multicast optimization
- Rate limiting for better bandwidth allocation
- Port Trunking (Link Aggregation LAG)
- Port mirroring for network monitoring
- Jumbo frame support

Management features
Web-based management Yes
Quality of Service (QoS) support Yes
Switch layer L2
Switch type Managed
Ports & interfaces
Power connector DC-in jack
Console port RJ-45
SFP+ module slots quantity 1
Basic switching RJ-45 Ethernet ports type 10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity 8
Network
Number of VLANs 64
VLAN support Yes
Auto MDI/MDI-X Yes
Broadcast storm control Yes
Port mirroring Yes
Copper ethernet cabling technology 10GBASE-T, 100BASE-TX, 1000BASE-T
10G support Yes
Networking standards IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3u, IEEE 802.3z
Data transmission
Jumbo frames support Yes
MAC address table 32000 entries
Security
IGMP snooping Yes
DHCP features DHCP client
Multicast features
Number of multicast groups filtered 128
Multicast support Yes
Design
Safety UL/cUL 60950, CB, KC, CCC
Number of fans 2 fan(s)
LED indicators Yes
Product colour Black
Rack mounting Yes
Performance
Mean time between failures (MTBF) 221813 h
Buffer size 2000 KB
Noise level 34.7 dB
Power
Power consumption (typical) 58.8 W
Input current 2.2 A
AC input frequency 50 - 60 Hz
AC input voltage 100 - 240 V
Number of power supply units 1
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating relative humidity (H-H) 0 - 90%
Operating temperature (T-T) 0 - 50 °C
Weight & dimensions
Weight 3.6 kg
Height 43 mm
Depth 207 mm
Width 330 mm
Packaging content
Rack mount kit Yes
Quick start guide Yes
Cables included AC
Packaging data
Resource CD Yes
Certificates
Certification CE, FCC, EN 55022, VCCI, C-Tick, KC, CCC
