Hanwha XRN-6410DB4 network video recorder Black
£3,980.99
Couldn't load pickup availability
- Up to 64 channels, Supports up to 32 megapixel camera resolution
- 400Mbps network camera recording
- Support 4K video out on HDMI monitor
- Support dual monitor video out
- H.265, H.264, MJPEG compression
- WiseStream support
- Maximum 16 internal HDDs (160TB)
- Support RAID 5/6
- ARB & failover(N+1), dynamic event, AI metadata search support
| Performance | |
|---|---|
| Audio system | 2-way |
| PTZ control | Yes |
| Input bandwidth | 400 Mbit/s |
| Output bandwidth | 32 Mbit/s |
| Audio codecs | G.711, G.726, AAC |
| Maximum resolution | 3840 x 2160 pixels |
| Alarm output channels | 4 |
| Alarm input channels | 8 |
| Video input channels | 64 channels |
| Wireless LAN features | |
|---|---|
| Wi-Fi | No |
| Hard drive | |
|---|---|
| RAID levels | 5, 6 |
| RAID support | Yes |
| HDD interface | SATA, SATA II, SATA III |
| Maximum storage capacity | 160 TB |
| Number of HDDs supported | 16 |
| HDD capacity | 0 GB |
| Ports & interfaces | |
|---|---|
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (ProfileS), SUNAPI(Server, Client) |
| Audio RCA outputs | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 2.0 ports quantity | 2 |
| HDMI output | Yes |
| HDMI ports quantity | 2 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 3 |
| Features | |
|---|---|
| LED indicators | Yes |
| Reset button | Yes |
| Product colour | Black |
| Power | |
|---|---|
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 265 W |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 20 - 85% |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
|---|---|
| Weight | 14.1 kg |
| Height | 132 mm |
| Depth | 571.1 mm |
| Width | 440 mm |
