£73.99

Stock Available: 0
  • Uses standards Cat.6 UTP or higher network cables (not included)
  • Supports USB 2.0 High Speed transfer rates up to 480Mbps
  • Robust aluminium housing with mounting points

Can be deployed between the transmitter and receiver unit of USB 2.0 Extender Nr. 42710 or KVM Extender Nr. 39245 to extend signals up to 280m
Uses standards Cat.6 UTP or higher network cables (not included)
Includes a Multi-Country Power Supply
Robust aluminium housing with mounting points
2 year warranty

The Lindy 280m Signal Repeater extends the distance between the transmitter and receiver of the Extender to distances of 280m. It connects to the transmitter and receiver unit of the Extender by using Cat.6 UTP or higher network cables. Distances up to 240m can be achieved when using Cat.5e UTP/STP cabling.

With a robust aluminium housing and mounting points, it is the ideal solution for providing remote access to printers, scanners, web cams and external HDD & flash drive storage. The Extender is also perfect for digital signage applications, home network integration, industrial control, security, USB device sharing and KVM extension. The included power supply for the receiver unit ensures secure and uninterrupted power to all devices.

Performance
Chipset AST1620
Cable types supported Cat5e, Cat6
Data transfer rate 480 Mbit/s
Maximum transfer distance 280 m
Type Network repeater
Ports & interfaces
DC-in jack Yes
Ethernet LAN (RJ-45) ports 2
Design
Certification CE, FCC, RoHS & REACH, CP65
Quantity per pack 1 pc(s)
LED indicators Yes
Housing material Aluminium
Product colour Black
Power
Included power plug types EU, UK, US
Output current 2.6 A
Output voltage 5 V
Operational conditions
Operating relative humidity (H-H) 0 - 95%
Storage temperature (T-T) -20 - 85 °C
Operating temperature (T-T) 0 - 55 °C
Weight & dimensions
Weight 162 g
Height 27 mm
Depth 110 mm
Width 67 mm
Packaging content
Manual Yes
AC adapter included Yes
Packaging data
Package weight 300 g
Package height 85 mm
Package depth 115 mm
Package width 115 mm
Package type Box
Certificates
Compliance certificates RoHS
Logistics data
Harmonized System (HS) code 85176990
