ATEN 2-Port True 4K DisplayPort MST Hub
£90.99
Couldn't load pickup availability
- Distributes one True 4K source to two DisplayPort displays at the same time
- Allows for Single Stream Transport (SST) or Multi-Stream Transport (MST) Mode
- Supports 4K resolution for dual output – up to 3840 x 2160@30Hz (4:4:4)
- DisplayPort 1.2; HDCP 1.3 compliant
- Provides Dolby TrueHD and DTS-HD Master 7.1 Audio channel
- High quality and durable aluminum enclosure
Designed with a cost effective, yet advanced DisplayPort MST solution in mind, the ATEN VS92DP 2-Port True 4K DisplayPort MST Hub allows the high-defi nition video to be transmitted to two different locations without losing quality. Productivity is enhanced with its feature that permits up to two displays to be connected to a Windows-based laptop / PC. Meanwhile, users can mirror the same image onto two displays or display independent content to each display for multitasking.
1x VS92DP 2-Port True 4K DisplayPort MST Hub
1x USB Type-A to USB Micro-B cable
1x user instructions
| Ports & interfaces | |
|---|---|
| Video out | 2x DisplayPort |
| Video port type | DisplayPort |
| Video ports quantity | 2 |
| Features | |
|---|---|
| LED indicators | Status |
| HDCP | Yes |
| Cable length | 0.15 m |
| HDCP version | 1.3 |
| HD type | 4K Ultra HD |
| Maximum resolution | 3840 x 2160 pixels |
| Housing material | Aluminium |
| Product colour | Black |
| Power | |
|---|---|
| Power consumption (max) | 2 W |
| Weight & dimensions | |
|---|---|
| Weight | 120 g |
| Height | 150 mm |
| Depth | 88 mm |
| Width | 60 mm |
| Packaging data | |
|---|---|
| Package weight | 200 g |
| Package height | 160 mm |
| Package depth | 119 mm |
| Package width | 59 mm |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Logistics data | |
|---|---|
| Products per master (outer) case | 10 pc(s) |
| Master (outer) case gross weight | 2.34 kg |
| Master (outer) case height | 338 mm |
| Master (outer) case length | 490 mm |
| Master (outer) case width | 315 mm |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case net weight | 1.2 kg |
