HPE ProLiant DL360 Gen10 Plus 4310 12c 1P 2x32GB-R SR416i-a 2x480GB SATA SSD 2x800W PS EU Server
Couldn't load pickup availability
- Intel Xeon Silver 4310 2.1 GHz
- 64 GB 3200 MHz DDR4-SDRAM 2 x 32
- 960 GB
- Rack (2U) 800 W
Do you need to efficiently expand or refresh your IT infrastructure to propel the business? Adaptable for diverse workloads and environments, the compact 1U HPE ProLiant DL360 Gen10 Plus server delivers enhanced performance with the right balance of expandability and density. Designed for supreme versatility and resiliency while backed by a comprehensive warranty, the HPE ProLiant DL360 Gen10 Plus server is ideal for IT infrastructure, either physical, virtual, or containerized. Powered by 3rd Generation Intel Xeon Scalable Processors, delivering up to 40 cores, 3200 MT/s memory, and introducing PCIe Gen4 and Intel Software Guard Extension (SGX) support to the dual-socket segment, the HPE ProLiant DL360 Gen10 Plus server delivers premium compute, memory, I/O, and security capabilities for customers focused on performance at any cost.
What is new supporting point:
Supports 3rd Generation Intel Xeon Scalable Processors for enhanced compute performance.
64 PCIe Gen4 lanes, resulting in more devices, improved bandwidth and augmented balanced I/O capabilities.
Support for industry-standard OCP 3.0 Network Adapters, enhancing customer choice.
Enhanced storage capabilities with Tri-mode controllers supporting NVMe/SAS/SATA drives, allowing customers to select the ideal media type and mix for their exact application.
Choice of storage backplanes and cages, offering diverse bay counts, protocols, and bandwidth that enable customers to design their server storage for their precise needs.
Slot-less HW RAID protected M.2 boot solution, providing peace-of-mind O/S deployment while saving invaluable slots and storage bays.
| Processor | |
|---|---|
| Number of processors installed | 1 |
| Motherboard chipset | Intel C621A |
| Processor cache | 18 MB |
| Processor cores | 12 |
| Processor boost frequency | 3.3 GHz |
| Processor frequency | 2.1 GHz |
| Processor model | 4310 |
| Processor generation | 3rd Generation Intel® Xeon® Scalable |
| Processor family | Intel Xeon Silver |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Maximum internal memory | 8 TB |
| Memory slots | 16x DIMM |
| Memory clock speed | 3200 MHz |
| Memory layout (slots x size) | 2 x 32 GB |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 64 GB |
| Storage | |
|---|---|
| Optical drive type | No |
| Supported RAID controllers | None |
| RAID levels | 0, 1, 5, 10 |
| RAID support | Yes |
| SSD interface | PCI Express 4.0 |
| SSD capacity | 480 GB |
| Number of SSDs installed | 2 |
| Total storage capacity | 960 GB |
| Network | |
|---|---|
| LAN controller | Broadcom BCM5719 |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 4 |
| Design | |
|---|---|
| Rack mounting | Yes |
| Product colour | Black, Grey |
| Chassis type | Rack (2U) |
| Performance | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
|---|---|
| Operating system installed | No |
| Power | |
|---|---|
| Number of main power supplies | 2 |
| Number of redundant power supplies installed | 1 |
| Power supply | 800 W |
| Redundant power supply (RPS) support | Yes |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 8 - 90% |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating temperature (T-T) | 10 - 35 °C |
| General | |
|---|---|
| Product family | ProLiant |
| Product series | DL |
| Weight & dimensions | |
|---|---|
| Depth | 434.6 mm |
| Height | 42.9 mm |
| Width | 434.6 mm |
