HPE Xeon Intel -Gold 6348H (2.3GHz/24-core/165W) Processor Kit for Superdome Flex 280
£4,929.99
Couldn't load pickup availability
- Intel® Xeon® Gold 6348H 2.3 GHz
- 33 MB L3 LGA 4189
- Processor cores: 24 14 nm 64-bit 165 W
- Maximum internal memory supported by processor: 1.15 TB DDR4-SDRAM
- Tray
.
| Processor | |
|---|---|
| Processor ARK ID | 204095 |
| Processor codename | Cooper Lake |
| Thermal Design Power (TDP) | 165 W |
| Processor cache type | L3 |
| Processor cache | 33 MB |
| Processor boost frequency | 4.2 GHz |
| Processor operating modes | 64-bit |
| Processor threads | 48 |
| Component for | Server/workstation |
| Cooler included | No |
| Processor lithography | 14 nm |
| Processor socket | LGA 4189 |
| Processor cores | 24 |
| Processor base frequency | 2.3 GHz |
| Processor model | 6348H |
| Processor generation | 3rd Generation Intel® Xeon® Scalable |
| Processor family | Intel® Xeon® Gold |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Hexa-channel |
| Memory clock speeds supported by processor | 2933 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Maximum internal memory supported by processor | 1.15 TB |
| Graphics | |
|---|---|
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card | No |
| Features | |
|---|---|
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Export Control Classification Number (ECCN) | 5A992C |
| Scalability | 4S |
| Embedded options available | No |
| PCI Express CEM revision | 3.0 |
| Supported instruction sets | SSE4.2, AVX, AVX 2.0, AVX-512 |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 48 |
| Market segment | Server |
| Execute Disable Bit | Yes |
| Processor special features | |
|---|---|
| Intel® Optane™ DC Persistent Memory technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Optane™ DC Persistent Memory Supported | Yes |
| Intel® Run Sure Technology | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Speed Shift Technology | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| General | |
|---|---|
| Product family | Xeon |
| Packaging data | |
|---|---|
| Package type | Tray |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85423119 |
| Technical details | |
|---|---|
| Launch date | Q2'20 |
| Status | Launched |
| Memory speed (max) | 2933 MHz |
| Number of UPI links | 6 |
| Target market | Cloud Computing |
| Product type | Processor |
| Weight & dimensions | |
|---|---|
| Processor package size | 77.5mm x 56.5mm |
| Depth | 190.5 mm |
| Width | 136.4 mm |
| Other features | |
|---|---|
| Maximum internal memory | 1.12 TB |
