• Managed
• Basic switching RJ-45 Ethernet ports quantity: 4
• 10G support
• Switching capacity: 120 Gbit/s
• 1U Rack mounting
• Power supply included Power over Ethernet (PoE)

Powerful Enterprise Switch Models
The UniFi Switch delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. Its auto-sensing PoE ports deliver up to 60W of power per port.

10 Gbps Deployment Example
Multiple switches connect via SFP+ to the UniFi Switch 16 XG. One UniFi Switch XG 6POE delivers data and 802.3bt PoE++ to multiple APs, the UniFi BaseStation XG, model UWB-XG, and the UniFi AP XG, model UAP-XG.

Multiple switches are daisy-chained through their SFP+ interfaces.

Convenient PoE++ Support
The UniFi Switch features auto-sensing IEEE 802.3af/at/bt PoE to power multiple devices on the network.

10G High-Capacity Links
The UniFi Switch offers maximum performance and low latency as an aggregation switch. For fiber connectivity, it features 2 SFP+ ports. For CAT 6/5e cable connectivity, the US-XG-6-POE offers 4 1/2.5/5/10Gbps RJ45 ports.

Seamless Integration
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.
