£5,547.99

Stock Available: 0
  • 1000 Mbit/s
  • Power over Ethernet (PoE)
  • Rack mounting
  • Black

The HPE Aruba Networking 9100 Series Hybrid Gateway is a cloud-optimized edge appliance designed to securely and seamlessly extend enterprise services to medium branch, large branch and small campus networks. Using cloud architecture scale and efficiency together with intelligent edge device security and performance capabilities, the 9100 Hybrid Gateway delivers scalable, high-performance Wi-Fi with enhanced security to the edge. This purpose-built high-performance edge appliance delivers seamless roaming, 24/7 reliability, and always-on connectivity - even during upgrades. Intelligent automation, AI insights, and unified infrastructure management, delivered by AOS-10 and HPE Aruba Networking Central, simplify and power IT operations. This versatile gateway provides advanced wireless capabilities, intelligent routing with both wireless and wired tunnel orchestration, and automated and unified role-based policy enforcement for users and IoT across LAN, WAN, and SD-WAN.

What is new supporting point:
Always-on high availability with live upgrades, clustering, and redundancy.
Versatile scalable platform for cloud-based wireless gateway, SD-branch device, or VPN concentrator use cases.
Cloud-native AOS-10 architecture as part of HPE Aruba Networking Central provides IT operational efficiency with unified cloud-based management and control of wired, wireless, and SD-WAN.
Scales to meet medium branch, large branch and small campus needs supporting up to 4K APs and 10K clients.
High-speed wired connectivity with 10GbE fiber ports for up to 20Gbps throughput.
Dynamic segmentation for automated role-based policy enforcement across users, devices, and IoT.

Design
LED indicators Power, Status
Mounting type Rack mounting
Rack capacity 1U
Product colour Black
Features
Mean time between failures (MTBF) 236076 h
Performance
Control display unit No
Protocols
DHCP client Yes
Network
Firewall throughput 10000 Mbit/s
3DES/AES throughput 10 Gbit/s
Ethernet LAN data rates 1000 Mbit/s
Security
MAC address filtering Yes
Access Control List (ACL) Yes
Ports & interfaces
SFP+ ports quantity 2
Combo SFP ports quantity 2
Ethernet LAN (RJ-45) ports 2
Console port RJ-45
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 1
Power
Heat dissipation 290 BTU/h
Power over Ethernet (PoE) Yes
Output voltage 54 V
Input frequency 50 - 60 Hz
Input voltage 100 - 240 V
Power consumption (max) 150 W
Weight & dimensions
Weight 2.31 kg
Width 294.8 mm
Depth 201.1 mm
Height 43.7 mm
Operational conditions
Storage relative humidity (H-H) 10 - 95%
Operating relative humidity (H-H) 10 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
General
Product family Aruba Networking
Certificates
Certification None
