Jonsbo V10 Silver
Couldn't load pickup availability
- PC
- ITX
- Supported HDD sizes: 2.5"
- Number of 2.5" bays: 2
- Side window Anti-dust filter
- Aluminium, Steel
- Silver
The concept is to create an ITX case which suitable for high-performance CPU and long graphics card.
There is space for 240 AIO radiator at the top, two 120mm fans at the bottom for superb heat convection
| Design | |
|---|---|
| Maximum PSU length | 15 cm |
| Maximum graphics card length | 33 cm |
| Maximum CPU cooler height | 7.5 cm |
| Anti-dust filter | Yes |
| Side window | Yes |
| Number of expansion slots | 2 |
| Number of 2.5" bays | 2 |
| Supported motherboard form factors | ITX |
| Product colour | Silver |
| Material | Aluminium, Steel |
| Type | PC |
| Power supply | |
|---|---|
| Supported power supply form factors | PS2, SFX, SFX-L |
| Power supply included | No |
| Ports & interfaces | |
|---|---|
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Cooling | |
|---|---|
| Bottom fans diameters supported | 120 mm |
| Number of bottom fans supported (max) | 2 |
| Top fans diameters supported | 120 mm |
| Number of top fans supported (max) | 2 |
| Storage | |
|---|---|
| Supported HDD sizes | 2.5" |
| Weight & dimensions | |
|---|---|
| Weight | 3.6 kg |
| Height | 304 mm |
| Depth | 344 mm |
| Width | 174 mm |
