C2G C2G54263 AV extender AV transmitter & receiver Black
£166.99
Couldn't load pickup availability
- Two USB-C ports for host PC connection
- Two USB-C ports and two USB-A ports for connecting devices
- Supports USB 3.2 Gen 1 with data transfer speeds up to 5Gbps
- Supports auto-switching when new devices are detected or manual switching via the front panel button or RS-232 API commands
- Compatible with a broad range of USB sources and devices
For switching between two USB-C sources and two USB-C or USB-A devices, this device supports automatic switching by detecting a new source or manual switching via the front panel button or RS-232 API commands. It supports USB 3.2 Gen 1 with data transfer rates up to 5 Gbps and is compatible with a wide range of USB peripherals, including webcams, PTZ cameras, keyboards, mice, printers, displays, and more. This plug-and-play device is versatile and easy to use.
| Features | |
|---|---|
| Product colour | Black |
| Control type | Buttons |
| On/off switch | Yes |
| Cable length | 1.5 m |
| Material | Aluminium |
| Bandwidth | 5 Gbit/s |
| LED indicators | Power |
| RS-232 pass-through | Yes |
| Type | AV transmitter & receiver |
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB connector type | USB Type-A, USB Type-C |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity | 2 |
| Connectivity technology | Wired |
| Power | |
|---|---|
| Output current | 3 A |
| Input current | 1.5 A |
| Operating voltage (transmitter) | 12 V |
| AC input frequency | 50-60 Hz |
| AC input voltage | 100-240 V |
| Power source type | AC |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Weight & dimensions | |
|---|---|
| Receiver dimensions (WxDxH) | 125 x 80 x 30 mm |
| Weight | 498 g |
| Packaging data | |
|---|---|
| Package weight | 640 g |
| Quantity per pack | 1 pc(s) |
| Technical details | |
|---|---|
| Warranty period | 3 year(s) |
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA |
