Western Digital Ultrastar Data60 disk array 96 TB Rack (4U) Black
Now £21,227.99

We'll only use your email for this alert unless you tick the box. Unsubscribe any time.

We'll watch the price for 6 months and email you if it drops. Unsubscribe in one click.

Overview

  • Up to 60 Ultrastar HDDs (SAS or SATA)
  • Up to 1.2PB1 raw capacity in 4U using forthcoming 20TB SMR HDDs
  • Hybrid support for data acceleration tier with SSDs (SAS or SATA) in up to 24 of 60 drive slots
  • Dual-port SAS for high availability or single-port SATA for low cost
  • Enterprise-grade redundant and hot-swappable PSUs, I/O modules, and fans

The Ultrastar Data60 hybrid storage platform is a key element of next-generation disaggregated storage and Software-Defined Storage (SDS) systems. The compact, efficient form factor provides the flexibility to specify the HDD and SSD combinations for balancing capacity, performance, and cost.

A flash data acceleration tier can be enabled to serve both fast data and big data applications from a single platform. The Ultrastar Data60 addresses the demanding storage needs of large enterprise customers, storage OEMs, cloud service providers, as well as resellers/integrators requiring dense, shared HDD or hybrid storage.

Specifications

Storage

Storage drives installedYes
Installed storage drive typeHDD
Number of storage drives installed24
Total installed storage capacity96 TB
Supported storage drive typesHDD & SSD
Number of storage drives supported60
Storage drive interfaceSerial Attached SCSI (SAS) III
Storage drive size3.5"
Supported storage drive interfacesSAS-3, Serial ATA III
Data transfer rate12 Gbit/s
Hot-swap drive baysYes

Ports & interfaces

USB connectivityNo
Number of mini-SAS host ports12
Mini-SAS host portYes
Show all 33 specificationsShow fewer specifications

Design

Device classSmall & Medium Business
Chassis typeRack (4U)
Product colourBlack
LED indicatorsYes
Noise level72 dB
Number of fans6 fan(s)
Redundant fans supportYes

Power

Power supply unit (PSU) capacity1600 W
Number of power supply units2
Redundant power supply (RPS) supportYes
AC input frequency50 - 60 Hz

Weight & dimensions

Width447 mm
Depth712 mm
Height175 mm
Disk enclosure weight23.7 kg

General

Product familyUltrastar

Operational conditions

Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)5 - 85%
Storage temperature (T-T)-40 - 70 °C
