Viewsonic VPC12-WPO-16 embedded computer 2.3 GHz Intel® Core™ i5 256 G

Viewsonic

£1,038.99

Stock Available: 0

Product Information

High Definition Audio Stereo
Intel HD graphic 655
Max Resolution up to 4096x2304@60Hz

The ViewSonic® VPC12-WPO-16 slot-in PC is the ideal integrated solution for the ViewBoard® interactive displays and presentation displays. With dual-band Wi-Fi and Bluetooth, a powerful Intel® Core™ i5-8259U Processor, 8GB DDR4 SO-DIMM memory, and 256GB SSD storage, the VPC12-WPO-16 contains the computing power needed to operate CPU intensive applications.

Product Specifications

Processor
Maximum internal memory supported by processor	32 GB
Configurable TDP-down	20 W
Configurable TDP-down frequency	1.1 GHz
Thermal Design Power (TDP)	28 W
Processor threads	8
System bus rate	4 GT/s
Processor cache	6 MB
Processor boost frequency	3.8 GHz
Processor cores	4
Processor model	i5-8259U
Processor generation	8th gen Intel® Core™ i5
Processor family	Intel® Core™ i5
Processor manufacturer	Intel
Processor frequency	2.3 GHz

Memory
Memory slots	1x SO-DIMM
Internal memory type	DDR4-SDRAM
Internal memory	8 GB

Storage
SSD capacity	256 GB
SSD interface	M.2
Number of storage drives installed	1
Storage media	SSD
Total storage capacity	256 GB

Graphics
Graphics card HDMI ports quantity	1
Discrete graphics card	No
On-board graphics card 4K support	Yes
Maximum on-board graphics card memory	32 GB
On-board graphics card model	Intel Iris Plus Graphics 655
On-board graphics card	Yes

Network
Bluetooth Low Energy (BLE)	Yes
Bluetooth version	4.2
Bluetooth	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi	Yes

Ports & interfaces
HDMI version	1.4
HDMI ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 2.0 ports quantity	1

Performance
Product colour	Black
Built-in display	No

Software
Operating system architecture	64-bit
Operating system installed	Windows 10 Pro

Processor special features
Intel Virtualization Technology (VT-x)	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Clear Video Technology	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Stable Image Platform Program (SIPP)	No
Intel 64	Yes
Intel TSX-NI	No
Embedded options available	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Trusted Execution Technology	No
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel Flex Memory Access	Yes

Power
DC input voltage	12 / 19 V
Power consumption (typical)	65 W

Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-5 - 45 °C

Certificates
Certification	CE EMC, CE LVD, CE RED, RoHS, WEEE, BIS, WPC

Weight & dimensions
Package weight	1.1 kg
Package height	77 mm
Package depth	196 mm
Package width	254 mm
Weight	800 g
Height	30 mm
Depth	119 mm
Width	202 mm
