£1,554.99

Stock Available: 0
  • Remotely reboot outlets to power cycle unresponsive IT equipment or increase runtime of critical equipment upon power failure with outlet-level control
  • Reliable power distribution with local and remote power monitoring options offer quick access to critical power usage information to evaluate energy usage trends and maximize uptime
  • Environmental monitoring capabilities with the addition of optional environmental sensors ensure users have critical infrastructure data at their fingertips to prevent climate-related equipment failure and system downtime
  • Fault-Tolerant Daisy Chaining with RSTP simplifies intelligent rPDU connectivity and ensures data is reported even when a break in the network chain occurs. Supports up to 40 rPDUs
  • Daisy-chain up to 50 devices on a single IP address and reduce deployment time with self-configuration of downstream devices

Upgradeable Switched Unit Level Monitored rPDUs provide reliable power distribution to critical IT equipment while delivering individual outlet level control and a comprehensive view of input power usage via remote network access. Includes environmental monitoring capabilities to obtain real-time environmental metrics. Upgrade the hot-swappable monitoring device on select units to leverage new technologies and accommodate changing business needs.

Design
PDU types Switched
Type Three-phase
Rack capacity 0U
Mounting Horizontal
Product colour Black
Display LCD
Ports & interfaces
AC outlets quantity 12 AC outlet(s)
Power plug IEC 60309
AC outlet types C13 coupler, C19 coupler
Serial ports quantity 1
Ethernet LAN (RJ-45) ports 1
USB ports quantity 1
Features
Reset button Yes
Cable length 3 m
Management features
Monitoring Current, Power, Voltage
Supported network protocols DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+, Modbus TCP
Power
Nominal input voltage 200-240 V
AC input frequency 50/60 Hz
Maximum current 32 A
Load capacity 230 VA
Power protection features Over current
Certificates
Compliance certificates RoHS, UKCA, CE
Operational conditions
Operating temperature (T-T) 0 - 60 °C
Weight & dimensions
Width 432 mm
Depth 305 mm
Height 44 mm
Packaging data
Package weight 5.44 kg
General
Product family PowerIT
Logistics data
Warranty period 5 year(s)
