Synology · MPN: RX1217SAS/144TB-HAT5300
£12,147.99
inc. VAT
Spread the cost with Klarna, Float or SnapFrom 3 interest-free payments of £4,049.33 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Large Enterprise Business
  • Rack (2U) Black
  • HDD Storage drives installed 144 TB
  • Hot-swap drive bays
  • 500 W

Effortless capacity expansion for Synology FlashStation and RackStation solutions on-the-fly.

12-bay 3.5"/2.5" SAS/SATA expansion

Easily add 12 additional drive bays to Synology FlashStation or RackStation1. Supporting both 2.5" and 3.5" SAS/SATA drives, the RX1217sas is a flexible solution supporting on-the-fly volume expansion or serving as a local backup destination.

Maximum reliability design

Dual power supplies ensure continuous service uptime. Easily replace defective drives with the hot swappable drive trays. Experience fast and secure rack cabinet installation with the optional sliding rail kit RKS1317.

Specifications

Storage

Hot-swap drive baysYes
Storage drive sizes supported2.5,3.5"
Supported storage drive interfacesSAS, Serial ATA III
Storage drive capacity12 TB
Maximum supported storage capacity192 TB
Number of storage drives supported12
Supported storage drive typesHDD & SSD
Total installed storage capacity144 TB
Number of storage drives installed12
Installed storage drive typeHDD
Storage drives installedYes

Ports & interfaces

SAS host portYes
Number of SAS host ports2
USB connectivityNo
Show all 46 specificationsShow fewer specifications

Design

CertificationFCC, BSMI, EAC, RCM, KC
Compatible productsSynology FS6400, FS3600, FS3400, FS3017, FS2017, SA3600, SA3400, RS18017xs+
Rack railsYes
Fan diameter6 cm
Noise level60.9 dB
Number of fans4 fan(s)
CoolingYes
LED indicatorsYes
Product colourBlack
Chassis typeRack (2U)
Device classLarge Enterprise Business

Power

AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Power consumption (typical)132.7 W
Redundant power supply (RPS) supportYes
Number of power supply units2
Power supply unit (PSU) capacity500 W

Weight & dimensions

Weight18 kg
Height88 mm
Depth724 mm
Width482 mm

Packaging content

Drive bay lockingYes
Power cables quantity1
Cables includedAC, MiniSAS

Operational conditions

Operating altitude0 - 5000 m
Storage relative humidity (H-H)5 - 95%
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)5 - 95%
Operating temperature (T-T)5 - 35 °C

Sustainability

Sustainability complianceYes
Sustainability certificatesUL ECOLOGO

Other features

Compliance certificatesCE, RoHS
