Synology · MPN: RX1217/144TB-HAT5300
£10,875.99
inc. VAT
Spread the cost with Klarna, Float or SnapFrom 3 interest-free payments of £3,625.33 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Home & Home Office
  • Rack (2U) Black
  • HDD Storage drives installed
  • Hot-swap drive bays
  • 500 W

Synology gives you the flexibility to start with a smaller storage capacity and expand as your business starts to grow. RX1217 and RX1217RP are 12-bay storage expansion units designed to provide seamless capacity expansion for select Synology RackStations.

Volume expansion & backup

When drive capacity is running low on a Synology RackStation, Synology RX1217/RX1217RP offers an easy way to immediately expand storage by providing 12 additional drive slots. The RAID volume on the Synology RackStation can be expanded directly without having to reformat the existing hard drives, ensuring service continuity during the expansion process. To ensure 24/7 service uptime, Synology RX1217RP is equipped with redundant power supplies, allowing automatic failover support if one of the PSUs fail.

When created as a separate volume, Synology RX1217/RX1217RP also serves as an additional local backup destination for Synology RackStations.

Reliable plug-and-use design

Synology RX1217/RX1217RP securely connects to Synology RackStation servers with a high-bandwidth expansion cable, ensuring maximum data throughput and smooth operation — as if they are part of the internal drives of Synology RackStation. SATA 6Gb/s interface ensures the installed drives provide high quality, outstanding data processing performance.

Green & easy to manage

Hibernation mode can be manually configured to start automatically when the system has been inactive for a period of time. This not only saves energy but also extends the lifespan of hard drives. RX1217/RX1217RP will also smartly power on/off with the attached RackStation, so no user intervention is needed to keep this system running smartly and efficiently.

Specifications

Storage

Hot-swap drive baysYes
Data transfer rate6 Gbit/s
Supported storage drive interfacesSerial ATA II
Storage drive size2.5/3.5"
Storage drive interfaceSerial ATA III
Number of storage drives supported12
Supported storage drive typesHDD & SSD
Number of storage drives installed12
Installed storage drive typeHDD
Storage drives installedYes

Ports & interfaces

InfiniBandYes
USB connectivityNo
Show all 31 specificationsShow fewer specifications

Design

Compatible productsSynology RS4017xs+, RS3617xs+, RS3614xs+, RS3413xs+, RS3617xs, RS3617RPxs, RS3614(RP)xs, RS3412(RP)xs, RS3411(RP)xs, RS2416(RP)+, RS2414(RP)+, RS2212(RP)+, RS2211(RP)+
Noise level54.6 dB
Number of fans3 fan(s)
Product colourBlack
Chassis typeRack (2U)
Device classHome & Home Office

Power

AC input frequency50 - 60 Hz
AC input voltage100-240 V
Number of power supply units1
Power supply unit (PSU) capacity500 W

Weight & dimensions

Weight12.7 kg
Height88 mm
Depth664 mm
Width430.5 mm

Packaging content

Cables includedAC, InfiniBand

Operational conditions

Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)5 - 95%
Operating temperature (T-T)5 - 35 °C

Other features

Compliance certificatesRoHS
