Synology DiskStation DS2422+ NAS/storage server Tower Ryzen Embedded V1500B 4 GB DDR4 0 TB DiskStation Manager Black
Spread the cost with Klarna, PayPal, Float or SnapFrom 3 interest-free payments of £569.99 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
In stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Overview
- AMD Ryzen Quad-core 2.2 GHz
- 2,201/1,383 MB/s sequential read read/write throughput
- Easily add 10/25GbE and NVMe SSD cache
- Expand to 24 bays with one DX1222 expansion unit
Built for high-performance mass storage
The 12-bay Synology DiskStation DS2422+ is a capable choice for small and medium businesses with large storage, file sharing, and data protection requirements in a multi-user environment. It comes with powerful storage management, file syncing, surveillance, and backup software, and is suitable for editing high-quality video and as VM storage.
Faster performance
Comfortably run demanding applications and processes with multiple users on the DS2422+ while still enjoying a smooth and fast experience. See the improvements that help make your business productive.
Rise to the challenge
Prepare your DS2422+ for heavy workloads or upgrade flexibly as your business continues to grow. Use add-in cards to add bandwidth, fast SSD cache, or both.
Ready for remote work
Empower your workforce to collaborate, share files, and communicate from anywhere.
Certified virtual machine storage
DSM streamlines provisioning for and management of virtual machines with full certification for VMware® vSphere™, Microsoft® Hyper-V®, Citrix® XenServer™, and OpenStack virtualization environments.
Synology Storage Console for VMware® or Windows platforms lets you manage storage directly from your hypervisor. VMware® VAAI integration and Windows ODX help offload storage operations and speed up data transfer, and a Kubernetes CSI driver lets you provision and manage volumes directly from the K8s CLI.
Specifications
Storage
| Supported file systems | BTRFS, Fat, HFS+, NTFS, ext3, ext4 |
|---|---|
| Hot-swap drive bays | Yes |
| RAID levels | 0, 5, 6, 10, JBOD |
| RAID support | Yes |
| Maximum supported storage capacity | 108 TB |
| Storage drive sizes supported | 2.5,3.5" |
| Supported storage drive interfaces | Serial ATA, Serial ATA II, Serial ATA III |
| Storage drive capacity | 0 GB |
| Supported storage drive types | HDD & SSD |
| Installed storage drive type | No |
| Number of storage drives supported | 12 |
| Total installed storage capacity | 0 TB |
| Storage drives installed | No |
Processor
| Number of processors supported | 1 |
|---|---|
| Processor cores | 4 |
| Processor frequency | 2.2 GHz |
| Processor model | V1500B |
| Processor generation | AMD Ryzen Embedded V1000 Series |
| Processor family | Ryzen Embedded |
| Processor manufacturer | AMD |
Show all 71 specificationsShow fewer specifications
Memory
| Memory form factor | SO-DIMM |
|---|---|
| ECC | Yes |
| Memory slots | 2 |
| Maximum RAM supported | 32 GB |
| Internal memory type | DDR4 |
| Internal memory | 4 GB |
Network
| Link aggregation | Yes |
|---|---|
| Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| Wake-on-LAN ready | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Ethernet LAN | Yes |
Ports & interfaces
| PCI Express x8 (Gen 3.x) slots | 1 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 4 |
Design
| Drive bay locking | Yes |
|---|---|
| Fan diameter 2 | 12 cm |
| Fan diameter | 12 cm |
| Number of fans | 2 fan(s) |
| Product colour | Black |
| Cooling type | Active |
| Chassis type | Tower |
Performance
| Browser supported | Chrome, Firefox, Edge, Internet Explorer, Safari |
|---|---|
| Access Control List (ACL) | Yes |
| Web-based management | Yes |
| Noise level | 25 dB |
| Multilingual support | Yes |
| Backup features | Cloud, iSCSI LUN |
| Backup function | Yes |
| Device class | Small & Medium Business |
| Type | NAS |
Software
| Operating system installed | DiskStation Manager |
|---|
Power
| AC input frequency | 50 - 60 Hz |
|---|---|
| AC input voltage | 100 - 240 V |
| Power consumption (HDD standby) | 32.12 W |
| Power consumption (typical) | 73.11 W |
| Number of power supply units | 1 |
| Power supply unit (PSU) capacity | 550 W |
| Power supply location | Built-in |
General
| Product family | DiskStation |
|---|
Weight & dimensions
| Weight | 9.5 kg |
|---|---|
| Height | 270 mm |
| Depth | 340 mm |
| Width | 300 mm |
Packaging content
| Cables included | AC, LAN (RJ-45) |
|---|
Operational conditions
| Storage temperature (T-T) | -20 - 60 °C |
|---|---|
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
Other features
| Certification | FCCCEBSMIVCCIRCMUKCAEACCCCKCUL |
|---|---|
| Compliance certificates | RoHS |
