• AV matrix switcher Black
• Maximum resolution: 4096 x 2160 pixels
• HDCP EDID management
• Rack mounting 1U
• HDMI input ports quantity: 4 HDMI output ports quantity: 1 RJ-45 output ports: 3

The MUBT-44EC-Set is a cost-effective 4K30 HDBaseT Distribution Matrix with 3x HDBaseT and 1x HDMI output.

Supplied complete with HDBaseT receivers and associated accessories.
Only the matrix unit needs to be powered, as all the receivers are powered over the Cat6 (PoC).

Inputs can be selected by either the Front Panel buttons, IR, RS232, or Web GUI.
The selected source can be routed to any HDBaseT output, as well as the local HDMI output. 4K30 video is transmitted up to 40m, or 1080p @ 70m.
This rack mountable matrix supports bi-directional IR and is HDCP 1.4/2.2 compliant, with comprehensive EDID management.

Suitable for applications where simple cost effective multi-room distribution of HDMI video signals from 4 sources to 1 local display and 3 remote displays over HDBaseT up to 70m.
Typical uses include: residential multi-room, offices, reception areas, waiting rooms and shops.
