SY Electronics MFS51-18G HDMI/VGA/DisplayPort
Spread the cost with Klarna, PayPal, Float or SnapFrom 3 interest-free payments of £491.33 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- Supports inputs up to HDMI 2.0b 4K60 (18G)• 3x HDMI 2.0, 1x DisplayPort 1.2, 1x VGA inputs
- Full up/down scaler to 4K30
- HDCP 1.4 & 2.2 compliant
- HDBaseT output to 70m @1080p or 40m @4K30
- Extensive audio embedding and microphone functions
- Auto switch and monitor on/off options
- Easy EDID and HDCP Management
- Control: Front panel, IR, RS232, LAN, Contact closure
Powerful flexible scaling 4K presentation switcher with an input resolution up to 4K60 4:4:4 HDMI 2.0 18G and output at any resolutions up to 4K30 4:4:4
It offers fast switching between the 3 HDMI inputs,1 DisplayPort input,1 VGA input with and HDMI output together with an HDBaseT output.
Choose the selected source to be transmitted to the Single zone mirrored outputs.
Manual or Auto switching modes. Control via front panel , RS232, IR, Web GUI.
The unit allows for de-embedded stereo audio output, embedding any external audio input onto the selected video input, with line or microphone facility and phantom power.
Up or Down Scaled video signals are available as HDMI and HDBaseT (4K30 to 40m, 1080p to 70m – using Slim70 Edge).
The switcher can be controlled via front panel, RS232, IR, Web GUI, or an external push button control.It is suitable for a wide number of applications including classrooms, lecture halls and conference rooms.
Specifications
Ports & interfaces
| Video port type | HDMI/VGA/DisplayPort |
|---|---|
| HDMI ports quantity | 4 |
| HDMI version | 2.0b |
| HDMI in | 3 |
| Number of HDMI outputs | 1 |
| VGA (D-Sub) ports quantity | 1 |
| VGA (D-Sub) input ports | 1 |
| DisplayPorts quantity | 1 |
| Audio (L/R) in | 5 |
| Audio (L/R) out | 1 |
| RJ-45 output ports | 2 |
| 3.5 mm (1/8-inch) in | Yes |
| RS-232 ports | 1 |
| DC-in jack | Yes |
Features
| Product colour | Black |
|---|---|
| Rack capacity | 1U |
| Bandwidth | 10.2 Gbit/s |
| HD type | 2K Ultra HD |
| Supported video modes | 480i, 576p, 720i, 720p, 1080i, 1080p |
| Rack mounting | Yes |
| Maximum operating distance | 70 m |
| HDCP version | 1.4/2.2 |
| Maximum resolution | 3840 x 2160 pixels |
| LED indicators | Yes |
| HDCP | Yes |
Show all 32 specificationsShow fewer specifications
Power
| AC adapter output voltage | 24 V |
|---|---|
| AC adapter output current | 1.25 A |
| Power consumption (typical) | 8 W |
Certificates
| Certification | CE |
|---|
Weight & dimensions
| Width | 220 mm |
|---|
Packaging content
| Mounting kit | Yes |
|---|---|
| AC adapter included | Yes |
