StarTech.com ~HDMI Over IP Receiver for ST12MHDLAN2K - Video Wall Support - 1080p
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £108.99 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- Scalable video distribution system extends your HDMI video signal and RS232 control to one or multiple displays
- Create stunning video walls easily using a single video source with multiple receivers
- Manage and control your digital signage with our intuitive mobile app
- Crystal-clear picture quality, video resolutions up to 1080p
- Tidy, professional installation with included mounting hardware
HDMI® Video Over Cat5e or Cat6 |Scale to Multiple Displays |Mobile Control AppThis HDMI over IP receiver works with the HDMI Over IP Extender Kit (ST12MHDLAN2K, sold separately) and an Ethernet switch (sold separately), to receive HDMI video over your local area network (LAN) in remote locations, using Cat5e or Cat6 cabling. You can use additional receivers to distribute the HDMI signal to multiple locations or combine your remote displays to create a video wall.Highly ScalableIn a point-to-multipoint (one source to many screens) or multipoint-to-multipoint (many sources to many screens) configuration, you can output video to over 100 additional displays. Each display requires a receiver. Remote control of serial devices is supported through RS232 extension.Resolutions Up to 1080p, with AudioWith support for video resolution up to 1080p (1920 x 1080 at 60Hz), the transmitter also supports digital and analog audio to the receiver and analog audio from the receiver to the transmitter.Mobile Control with Included AppThe kit includes an easy-to-use online app to manage your IP video distribution.The app is available on iOS for your iPhone or iPad, Android for your smartphone or tablet, and Google Chrome browser for your desktop.Hassle-Free InstallationThe HDMI over IP receiver includes optional shelf-mounting hardware. It uses Cat5e or Cat6 cables and works with existing network infrastructures, eliminating the expense of running proprietary cables.ST12MHDLAN2R is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage
Specifications
Features
| Certification | CE, FCC, TAA |
|---|---|
| Product colour | Black |
| Rack mounting | Yes |
| Rubber feet | Yes |
| Daisy chain | Yes |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800, 1360 x 768 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080) |
| Material | Aluminium |
| LED indicators | Link, Power, Status |
| Audio output channels | 7.1 channels |
| Maximum transfer distance | 100 m |
| Cable types supported | Cat5e, Cat6 |
| Maximum resolution | 1920 x 1080 pixels |
| Type | AV receiver |
Ports & interfaces
| Audio input | 3.5 mm |
|---|---|
| Audio output | 3.5 mm |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| RJ-11 ports quantity | 2 |
| Number of HDMI outputs | 1 |
| RJ-45 input ports | 1 |
| Connectivity technology | Wired |
Show all 43 specificationsShow fewer specifications
Power
| Power plug type | Type M |
|---|---|
| External power adapter | Yes |
| Power consumption (typical) | 10 W |
| Output current | 1.5 A |
| Input current | 0.6 A |
| Operating voltage | 12 V |
| AC input voltage | 100 - 240 V |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Weight | 80 g |
|---|---|
| Height | 31 mm |
| Depth | 131 mm |
| Width | 118 mm |
Packaging content
| IR blaster included | Yes |
|---|---|
| IR receiver included | Yes |
| Mounting kit | Yes |
| Manual | Yes |
| Included power plug types | ANZ, EU, JP, NA, UK |
| Cables included | LAN (RJ-45), Phone (RJ-11) |
Technical details
| Audio support | Yes |
|---|---|
| Compliance certificates | RoHS |
