StarTech.com · MPN: ST12MHDLAN2R
£326.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £108.99 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Key specs

  • Maximum resolution1920 x 1080 pixels
  • Weight80 g
All specifications

Out of stock

FREE delivery

Express £9.99

Overview

  • Scalable video distribution system extends your HDMI video signal and RS232 control to one or multiple displays
  • Create stunning video walls easily using a single video source with multiple receivers
  • Manage and control your digital signage with our intuitive mobile app
  • Crystal-clear picture quality, video resolutions up to 1080p
  • Tidy, professional installation with included mounting hardware

HDMI® Video Over Cat5e or Cat6 |Scale to Multiple Displays |Mobile Control AppThis HDMI over IP receiver works with the HDMI Over IP Extender Kit (ST12MHDLAN2K, sold separately) and an Ethernet switch (sold separately), to receive HDMI video over your local area network (LAN) in remote locations, using Cat5e or Cat6 cabling. You can use additional receivers to distribute the HDMI signal to multiple locations or combine your remote displays to create a video wall.Highly ScalableIn a point-to-multipoint (one source to many screens) or multipoint-to-multipoint (many sources to many screens) configuration, you can output video to over 100 additional displays. Each display requires a receiver. Remote control of serial devices is supported through RS232 extension.Resolutions Up to 1080p, with AudioWith support for video resolution up to 1080p (1920 x 1080 at 60Hz), the transmitter also supports digital and analog audio to the receiver and analog audio from the receiver to the transmitter.Mobile Control with Included AppThe kit includes an easy-to-use online app to manage your IP video distribution.The app is available on iOS for your iPhone or iPad, Android for your smartphone or tablet, and Google Chrome browser for your desktop.Hassle-Free InstallationThe HDMI over IP receiver includes optional shelf-mounting hardware. It uses Cat5e or Cat6 cables and works with existing network infrastructures, eliminating the expense of running proprietary cables.ST12MHDLAN2R is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage

Specifications

Features

CertificationCE, FCC, TAA
Product colourBlack
Rack mountingYes
Rubber feetYes
Daisy chainYes
Supported graphics resolutions1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800, 1360 x 768 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
MaterialAluminium
LED indicatorsLink, Power, Status
Audio output channels7.1 channels
Maximum transfer distance100 m
Cable types supportedCat5e, Cat6
Maximum resolution1920 x 1080 pixels
TypeAV receiver

Ports & interfaces

Audio input3.5 mm
Audio output3.5 mm
Remote (IR) input1
Remote (IR) output1
RJ-11 ports quantity2
Number of HDMI outputs1
RJ-45 input ports1
Connectivity technologyWired
Show all 43 specificationsShow fewer specifications

Power

Power plug typeType M
External power adapterYes
Power consumption (typical)10 W
Output current1.5 A
Input current0.6 A
Operating voltage12 V
AC input voltage100 - 240 V

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Weight80 g
Height31 mm
Depth131 mm
Width118 mm

Packaging content

IR blaster includedYes
IR receiver includedYes
Mounting kitYes
ManualYes
Included power plug typesANZ, EU, JP, NA, UK
Cables includedLAN (RJ-45), Phone (RJ-11)

Technical details

Audio supportYes
Compliance certificatesRoHS
