StarTech.com 2-Port USB 3.1 (10Gbps) and eSATA PCIe Card - 1x USB-A and 1x eSATA
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £9.66 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
£4.95 delivery
Express £9.99
Spend £21.01 more for free delivery
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- Internal
- Host interface: PCIe
- Output interface: eSATA
- 10 Gbit/s
- Red
This combination PCI Express controller card lets you add both a USB 3.1 Gen 2 port and an eSATA port to your desktop PC, through a single PCIe slot. The versatile controller card offers a cost-effective way to add high-performance connectivity to your computer, with support for newer USB 3.1 devices as well as eSATA hard drives.
Fast transfers over USB 3.1 Gen 2
At up to 10Gbps, the USB 3.1 PCIe card delivers the speed you need for seamless performance from your compatible devices. It’s also backward compatible with previous versions of USB, so you can connect your existing USB 3.0 / 2.0 / 1.1 equipment.
Connect to eSATA devices
The controller card also connects your computer to an eSATA device, providing a hot-pluggable, high-speed storage solution for backing up or archiving data. With support for SATA I, II and III hard drives, and data transfer speeds of up to 6Gbps, the controller card offers reliable performance for your external SATA storage applications.
Versatile installation options
For added versatility, the controller card is equipped with a standard-profile bracket and includes a low-profile bracket for installation in small form-factor computers.
The PEXUSB311A1E is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Specifications
Ports & interfaces
| Port multiplier | No |
|---|---|
| eSATA ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| Expansion card standard | PCIe 3.0 |
| Output interface | eSATA |
| Host interface | PCIe |
Design
| Certification | CE, FCC, TAA, REACH |
|---|---|
| Product colour | Red |
| Internal | Yes |
Show all 23 specificationsShow fewer specifications
Features
| UASP support | Yes |
|---|---|
| Data transfer rate (max) | 10 Gbit/s |
| Chipset | ASMedia - ASM2142, ASMedia - ASM1351 |
Operational conditions
| Operating relative humidity (H-H) | 15 - 90% |
|---|---|
| Storage temperature (T-T) | -25 - 70 °C |
| Operating temperature (T-T) | 5 - 50 °C |
Technical details
| Compliance certificates | RoHS |
|---|
System requirements
| Server operating systems supported | Windows Server 2012, Windows Server 2016, Windows Server 2019 |
|---|---|
| Linux operating systems supported | Yes |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
Weight & dimensions
| Weight | 46 g |
|---|---|
| Height | 100 mm |
| Depth | 93 mm |
| Width | 80 mm |
