Shuttle PD01 Gigabit LAN with PoE Input (Power In) Internal Ethernet
£65.99
Couldn't load pickup availability
- Wired
- Ethernet
- Gigabit Ethernet
- Internal Component for: PC
The PD01 enables power supply of the EN01 via PoE
The optional Shuttle Accessory PD01 is a daughterboard for the EN01 series which provides a second Gigabit network port with Power-over-Ethernet (PoE) function. This enables the EN01 to receive power over the same network cable that transports data, and so does away with the need for a nearby power outlet. The power comes from a PoE-enabled Ethernet switch or from a power injector at the other end of the network cable.
| Ports & interfaces | |
|---|---|
| Connectivity technology | Wired |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 1 |
| Network | |
|---|---|
| Networking standards | IEEE 802.3at |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Design | |
|---|---|
| Internal | Yes |
| Component for | PC |
| Product colour | Black, Blue |
| Country of origin | China |
| Compatible products | Shuttle Edge EN01J3, EN01J4, EN01E, EN01B |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85176990 |
