Phanteks T30-140 Computer case Fan 14 cm Grey 1 pc(s)
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £30.33 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
In stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Overview
- Computer case Fan 14 cm 2500 RPM
- 44.3 dB 140 cfm 5.41 mmH2O
- Pulse-width modulation (PWM) support
- 140 x 140 x 30 mm 405 g
- Grey
- 1 pc(s)
The Ultimate Fan
The Phanteks T30 fan brings unparalleled performance to PC cooling for any scenario. With its built-in fan profiles and wide RPM range, the T30 can be tuned for silent, balanced, or extreme performance operation via a simple switch. With many years of development, extensive testing, and experience in chassis and air/water cooler design, the T30 combines the best aerodynamic design and quality components.
Both the fan blades and fan frame are made from the absolute best glass fiber reinforced Liquid Crystal Polymer (LCP) material. This makes the blades and frame extremely rigid and durable.
The T30 is designed with exceptional aerodynamic features, which require high-precision manufacturing. LCP enables this thanks to its great material properties. The tip of the fan blade has a continuous and small clearance (0.8 mm) to reduce turbulence and deliver unparalleled noise-normalized performance.
The Phanteks T30 features a unique 30 mm thick fan frame that results in a 25% larger fan blade. Combined with the LCP material, 3-phase motor, magnetic levitated DUAL VAPO bearing, and three PWM fan profiles, the T30-140 fan brings the best in silence, the best airflow performance, and the best in high pressure for the PC market.
Uncompromising Quality
Using glass fiber reinforced LCP (Liquid Crystal Polymer) for the fan blades and fan frame.
Increased thickness of 30 mm results in 25% thicker fan blades for much higher airflow
performance.
Designed for PC cooling with aerodynamic optimizations for uncompromised performance in dust filter-equipped chassis and dense radiators.
Unparalleled Performance
Precise load balancing to minimize noise from vibrations.
Aerofoil-shaped blades for increased static pressure.
Parallel 0.9 mm gap between blades and frame for improved performance and reduced turbulence.
Smooth and powerful 3-phase motor (6 poles) operates with a lower frequency response for excellent sound quality.
Specifications
Performance
| Mean time between failures (MTBF) | 150000 h |
|---|---|
| Fan speed (max) | 2500 RPM |
| Fan static pressure | 5.41 mmH2O |
| Quantity per pack | 1 pc(s) |
| Fan noise level (max) | 44.3 dB |
| Pulse-width modulation (PWM) support | Yes |
| Fan 2 maximum air pressure | 5.41 mmH2O |
| Fan 2 maximum airflow | 140 cfm |
| Fan 2 noise level (high speed) | 44.3 dB |
| Fan 2 rotational speed (max) | 2500 RPM |
| Maximum air pressure | 5.41 mmH2O |
| Maximum airflow | 140 cfm |
| Noise level (high speed) | 44.3 dB |
| Rotational speed (max) | 2500 RPM |
| Fan diameter | 14 cm |
| Type | Fan |
| Suitable location | Computer case |
Design
| Fan connector | 4-pin |
|---|---|
| Number of fan blades | 7 |
| Number of fans | 3 fan(s) |
| Product colour | Grey |
Show all 36 specificationsShow fewer specifications
Power
| Maximum current | 0.56 A |
|---|---|
| Fan power consumption | 6.72 W |
| Rated voltage | 12 V |
| Voltage | 10.2 - 13.2 V |
Weight & dimensions
| Package weight | 1.4 kg |
|---|---|
| Fan 2 dimensions (W x D x H) | 140 x 140 x 30 mm |
| Fan weight | 405 g |
| Fan thickness | 3 cm |
| Fan dimensions (W x D x H) | 140 x 140 x 30 mm |
| Weight | 1.11 kg |
| Height | 140 mm |
| Depth | 30 mm |
| Width | 140 mm |
Packaging content
| Number of screws | 36 |
|---|---|
| Screws included | Yes |
