NETGEAR XS724EM Managed L2 10G Ethernet (100/1000/10000) 1U Blue, Grey
Spread the cost with Klarna, PayPal, Float or SnapFrom 3 interest-free payments of £574.99 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- Managed L2
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 24
- 10G support
- MAC address table: 32000 entries Switching capacity: 480 Gbit/s
- 1U Rack mounting
- AC
Unlock your Network Potential with 10-Gigabit/Multi-Gigabit 5-Speed Networking Switches
Revolutionary 5-speed 10-Gigabit/Multi-Gigabit technology built in the NETGEAR multi-speed switches allows your devices to speed past the Gigabit barrier.
With the growth of virtualization, flash Storage, 4K videos , video streaming and IP surveillance, SMB networks need to extend beyond 1 Gigabit barrier. The 10-Gigabit/Multi-Gigabit Smart Managed Plus series from NETGEAR presents the right solution for this requirement; delivering unprecedented 10-Gigabit/Multi-Gigabit bandwith at an affordable cost.
Each port automatically detects which speed is needed by the connected device and provides the adequate speed. As opposed to regular 10-Gigabit switches that will only provide 1-Gigabit connectivity to any device that require less than 10-Gigabit, the XS512EM and XS724EM gives the exact speed required, no downgrade. Also, the new NETGEAR Multi-speed switch ports can be connected with regular Cat5E Ethernet cables, without the need to upgrade to Cat6/Cat6A wiring, therefore reducing wiring costs and hassle
Specifications
Management features
| Quality of Service (QoS) support | Yes |
|---|---|
| Switch layer | L2 |
| Switch type | Managed |
Ports & interfaces
| Power connector | DC-in jack |
|---|---|
| SFP+ module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
Show all 42 specificationsShow fewer specifications
Network
| Virtual LAN features | Port-based VLAN |
|---|---|
| VLAN support | Yes |
| Broadcast storm control | Yes |
| 10G support | Yes |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Data transmission
| Packet buffer memory | 3 MB |
|---|---|
| Jumbo frames | 9000 |
| Jumbo frames support | Yes |
| Store-and-forward | Yes |
| Switching capacity | 480 Gbit/s |
| MAC address table | 32000 entries |
Security
| MAC address filtering | Yes |
|---|---|
| IGMP snooping | Yes |
| DHCP features | DHCP client |
Design
| Number of fans | 3 fan(s) |
|---|---|
| LED indicators | Yes |
| Product colour | Blue, Grey |
| Form factor | 1U |
| Rack mounting | Yes |
Performance
| Mean time between failures (MTBF) | 830493 h |
|---|
Power
| Input current | 2 A |
|---|---|
| AC input voltage | 100 - 240 V |
| Power source | AC |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | No |
|---|
Operational conditions
| Heat dissipation | 513.88 BTU/h |
|---|---|
| Storage relative humidity (H-H) | 0 - 95% |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 50 °C |
Weight & dimensions
| Weight | 3.72 kg |
|---|---|
| Height | 43 mm |
| Depth | 204 mm |
| Width | 440 mm |
Sustainability
| Sustainability certificates | ENERGY STAR |
|---|
Certificates
| Certification | 47 CFR FCC, ICES-003:2016, ANSI C63.4:2014, EN55032:2012+AC:2013, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 32:2013, VCCI-CISPR32:2016, CNS 13438, IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013, UL 60950-1, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015 CNS14336-1 |
|---|
