Lindy HDMI ARC Audio Downmix Decoder
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £21.66 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- ARC Enabled: Extract audio signal from ARC (Audio Return Channel) enabled HDTV to analogue stereo output, for audio receiver/amplifier/headphones
- Support PCM 2.0, Dolby 5.1, DTS 5.1 audio downmix to 2 channel stereo audio output
- CEC Pass Through
- 2 Year Warranty
The Lindy HDMI ARC Audio Downmix Decoder of high quality audio signal to be simultaneously extracted and split to both digital and analog audio outputs, providing high quality audio and video performance, for a high quality audio experience of movies, music and games. Effortlessly adjust TV sound and speaker sound synchronously with CEC passthrough allowing you to increase or decreases the TV volume with your regular remote. The separate micro-USB port is used for power, via connection to a source devices USB port, avoiding the need for a separate PSU.
The converter's Dolby® Digital Decoder function ensures that Dolby® Digital audio signals are down-mixed to analogue stereo without any compression or loss in audio quality, and with support for PCM sample rates up to 192kHz and Dolby digital sample rates up to 48kHz, music and movies can be heard how the artist and sound engineers intended, with greater detail and clarity. Featuring flexible operation between all audio formats, and status LEDs, to indicate a Dolby Digital encoded audio source or for power, ensures simple, fuss-free installation and use.
Specifications
Inputs
| USB connector type | Micro-USB |
|---|---|
| HDMI in | 1 |
Outputs
| Audio (L/R) out | 1 |
|---|---|
| Headphone out | Yes |
Show all 23 specificationsShow fewer specifications
Technical details
| Sustainability compliance | Yes |
|---|---|
| Certification | California Proposition 65 |
| Product colour | Silver |
| Housing material | Plastic |
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS |
| Signal-to-Noise Ratio (SNR) | 101 dB |
| Warranty period | 2 year(s) |
| Supported sample rates | 192 kHz |
| Output impedance | 100 Ω |
| Chipset | SPHE8107S-AD |
| HDMI version | 1.3 |
| CEC pass-through | Yes |
| Frequency range | 20 - 20000 Hz |
Power
| Operating voltage | 5 V |
|---|
Weight & dimensions
| Height | 27 mm |
|---|---|
| Depth | 65 mm |
| Width | 70 mm |
Operational conditions
| Storage temperature (T-T) | -20 - 60 °C |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
