Lenovo · MPN: 7D73A047EA
£5,572.99
inc. VAT
Spread the cost with Klarna, Float or SnapFrom 3 interest-free payments of £1,857.66 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Key specs

  • Processor model4509Y
  • Internal memory32 GB
  • Internal memory typeDDR5-SDRAM
  • Memory clock speed5600 MHz
All specifications

Out of stock

FREE delivery

Express £9.99

Price drop alert

Lenovo ThinkSystem SR630 V3 server Rack (1U) Intel Xeon Silver 4509Y 2.6 GHz 32 GB DDR5-SDRAM 1100 W
Now £5,572.99

We'll only use your email for this alert unless you tick the box. Unsubscribe any time.

We'll watch the price for 6 months and email you if it drops. Unsubscribe in one click.

Overview

  • Intel Xeon Silver 4509Y (22.5MB Cache, 2.6GHz)
  • 32GB (5600MHz) DDR5-SDRAM (1 x 32)

The Lenovo ThinkSystem SR630 V3 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR630 V3 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.

This product guide provides essential pre-sales information to understand the ThinkSystem SR630 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR630 V3 and consider its use in IT solutions.

Specifications

Processor

Processor manufacturerIntel
Processor familyIntel Xeon Silver
Processor model4509Y
Processor frequency2.6 GHz
Processor boost frequency4.1 GHz
Processor cores8
Processor cache22.5 MB
Number of processors installed1
Maximum number of SMP processors2

Memory

Internal memory32 GB
Internal memory typeDDR5-SDRAM
Memory layout (slots x size)1 x 32 GB
Memory clock speed5600 MHz
ECCYes
Memory slots32x DIMM
Maximum internal memory8 TB
Show all 42 specificationsShow fewer specifications

Storage

RAID supportYes
RAID levels0, 1, 5, 6, 10, 50, 60
Supported RAID controllers9350-8i
Hot-swapYes
Internal drive bays8
Supported storage drive interfacesSAS
Optical drive typeNo

Graphics

On-board graphics cardYes
Maximum graphics card memory16 MB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
VGA (D-Sub) ports quantity1

Design

Chassis typeRack (1U)

Performance

Performance managementXClarity Controller Platinum
Trusted Platform Module (TPM) version2.0
Trusted Platform Module (TPM)Yes

Software

Compatible operating systemsMicrosoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Ubuntu Server

Power

Redundant power supply (RPS) supportYes
Power supply1100 W
Number of redundant power supplies supported2

General

Product familyThinkSystem

Weight & dimensions

Width440 mm
Height43 mm
Depth773 mm

Technical details

2.5" HDD support8
