Lenovo · MPN: 7Y51A07FEA
£2,153.99
inc. VAT
Spread the cost with Klarna, PayPal, Float or SnapFrom 3 interest-free payments of £717.99 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Key specs

  • Processor modelE-2246G
  • Memory clock speed2666 MHz
  • Internal memory typeDDR4-SDRAM
  • Weight9.1 kg
All specifications

Out of stock

FREE delivery

Express £9.99

Overview

  • No OS
  • Intel Xeon E-2246G (12MB Cache, 3.6GHz)
  • 16GB (2666MHz) DDR4-SDRAM (1 x 16)

Powerful and secure
The Lenovo ThinkSystem SR250 is a single-processor rack server that integrates power, reliability, flexibility, and security in a compact 1U form factor suited for the small-to-medium business.

The SR250 boasts a high price-performance ratio with a combination of high-processing capability and dependability with next-generation Intel® Xeon® E-2200 processors and support for an array of storage configurations.

It provides the flexibility to handle workloads including web serving, virtualization, entry-cloud and data-analytics applications, while integrated Intel Software Guard Extensions (SGX) secure the SR250 for blockchain applications.

Flexible and scalable
The ThinkSystem SR250 adapts to multiple environments and workloads in which a shorter-depth rack accommodates space-constrained environments. Also, lightning-fast TruDDR4 memory, GPU support, and an array of storage options, including low-latency NVMe drives, afford serious storage and workload flexibility.

Superb I/O capability via multiple network interface ports and a dedicated management port handle heavy network communications and enable faster data transmission.

The SR250 also features the option for either a fixed or redundant power supply unit depending on the data center deployment model. These options allow users to configure the SR250 to specifications appropriate for their distinct enterprise use and optimize server utility for future scalability.

Simple management
The ThinkSystem SR250 features the Lenovo XClarity Controller, the embedded management engine in all ThinkSystem servers that is designed to standardize, simplify, and automate foundation server management tasks.

Lenovo XClarity Administrator is a virtualized application that centrally manages ThinkSystem servers, storage, and networking, which can reduce provisioning time up to 95 percent versus manual operation. And running XClarity Integrator helps you streamline IT management, speed provisioning, and contain costs by seamlessly integrating XClarity into an existing IT environment.

Specifications

Processor

Thermal Monitoring TechnologiesYes
Maximum internal memory supported by processor128 GB
Execute Disable BitYes
Idle StatesYes
Processor socketLGA 1151 (Socket H4)
Processor lithography14 nm
Processor threads12
Processor operating modes64-bit
Processor codenameCoffee Lake
Tcase73 °C
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor2666 MHz
Maximum number of PCI Express lanes16
Processor package size37.5 x 37.5 mm
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Scalability1S
Embedded options availableNo
Maximum number of SMP processors1
Tjunction100 °C
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)80 W
Number of processors installed1
Motherboard chipsetIntel C246
Processor cache12 MB
Processor cores6
Processor boost frequency4.8 GHz
Processor frequency3.6 GHz
Processor modelE-2246G
Processor familyIntel Xeon E
Processor manufacturerIntel

Memory

Maximum internal memory128 GB
Memory slots4x DIMM
ECCYes
Memory clock speed2666 MHz
Memory layout (slots x size)1 x 16 GB
Internal memory typeDDR4-SDRAM
Internal memory16 GB
Show all 107 specificationsShow fewer specifications

Storage

Internal drive bays8
Optical drive typeNo
Hot-swapYes
RAID supportNo
SSD interfaceNVMe, NVMe 3.0, PCI Express 3.0
NVMeYes
Supported HDD sizes2.5"
HDD size2.5"
HDD interfaceSerial ATA III, Serial Attached SCSI (SAS)
Total storage capacity0 GB

Graphics

Maximum graphics card memory16 MB
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1200 MHz
Maximum on-board graphics card memory128 GB
On-board graphics card OpenGL version4.5
On-board graphics card DirectX version12.0
Number of displays supported (on-board graphics)3
On-board graphics card ID0x3E96
On-board graphics card modelIntel UHD Graphics P630
On-board graphics cardYes

Network

LAN controllerBroadcom BCM5720
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Ethernet interface typeGigabit Ethernet

Ports & interfaces

VGA (D-Sub) ports quantity1
Serial ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports3

Expansion slots

PCI Express slots version3.0
PCI Express x8 (Gen 3.x) slots2
PCI Express x4 (Gen 3.x) slots1

Design

Rack mountingYes
Rack railsYes
Product colourBlack
Chassis typeRack (1U)

Performance

Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0
Performance managementXClarity Standard

Software

Compatible operating systemsMicrosoft Windows Server 2016/2019, Red Hat Enterprise Linux 7/8, SUSE Linux Enterprise Server 12/15, VMware vSphere (ESXi) 6.5/6.7/7.0
Operating system installedNo

Processor special features

Intel TSX-NIYes
Intel Clear Video TechnologyYes
Intel® Secure KeyYes
Intel® OS GuardYes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology2.0
Intel® AES New Instructions (Intel® AES-NI)Yes
Processor ARK ID191043
Intel® Quick Sync Video TechnologyYes
Intel® InTru™ 3D TechnologyYes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
CPU configuration (max)1
Enhanced Intel SpeedStep TechnologyYes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Trusted Execution TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Software Guard Extensions (Intel SGX)Yes
Intel 64Yes
Intel Virtualization Technology (VT-x)Yes

Power

Number of main power supplies1
Number of redundant power supplies supported2
Power supply450 W
Redundant power supply (RPS) supportYes

General

Product familyThinkSystem

Weight & dimensions

Weight9.1 kg
Depth498 mm
Height43 mm
Width434 mm
