Lenovo THINKSYSTEM M.2 PM9A3 960GB PCI Express 4.0 NVMe V-NAND
£3,203.99
Couldn't load pickup availability
- 960 GB M.2 PCI Express 4.0
- Read speed: 5000 MB/s 550000 IOPS
- Write speed: 1400 MB/s 60000 IOPS
- V-NAND NVMe
- Hardware encryption
- S.M.A.R.T. support ECC
- Component for: Server/workstation
The ThinkSystem PM9A3 Read Intensive NVMe Solid-State Drives (SSDs) are general-purpose yet high-performance family of NVMe SSDs. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads.
This product guide provides essential presales information to understand the ThinkSystem PM9A3 Read Intensive NVMe SSDs offerings and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the PM9A3 SSDs and consider their use in IT solutions.
| Features | |
|---|---|
| SSD capacity | 960 GB |
| SSD form factor | M.2 |
| Interface | PCI Express 4.0 |
| NVMe | Yes |
| Memory type | V-NAND |
| Component for | Server/workstation |
| Hardware encryption | Yes |
| M.2 SSD size | 22110 (22 x 110 mm) |
| Read speed | 5000 MB/s |
| Write speed | 1400 MB/s |
| Random read (4KB) | 550000 IOPS |
| Random write (4KB) | 60000 IOPS |
| Random latency - read (up to) | 75 µs |
| Random latency - write (up to) | 30 µs |
| Sequential latency - read (up to) | 20 µs |
| Sequential latency - write (up to) | 20 µs |
| S.M.A.R.T. support | Yes |
| ECC | Yes |
| End-to-End Data Protection | Yes |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Drive writes per day (DWPD) | 1 |
| Mean time between failures (MTBF) | 2000000 h |
| Certification | c-UL-us CE TUV CB CE (EU) |
| Power | |
|---|---|
| Power consumption (read) | 7.5 W |
| Power consumption (write) | 6.5 W |
| Weight & dimensions | |
|---|---|
| Width | 22 mm |
| Depth | 110 mm |
| Height | 3.8 mm |
| Weight | 9 g |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Non-operating vibration | 20 G |
| Non-operating shock | 1500 G |
| Maximum operating altitude | 3050 m |
