Lenovo · MPN: 4XB7A17073
£868.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £289.66 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Hardened boot media that does not use a drive bay
  • Both mechanically & electronically designed to be more robust than any prior implementation
  • Design provides hardware mirroring of two M.2 SSDs
  • M.2 SSDs have higher mean time between failures (MTBF) than SD cards or USB keys
  • Tool-less clip design that supports back to back connector layout, providing simple install in limited space
  • When using configure-to-order (CTO), you can also select zero drives and add drives as a field upgrade

M.2 is a solid-state drive (SSD) form factor primarily used as an operating system boot solution. Lenovo ThinkSystem servers support M.2 drives either with the addition of a supported M.2 adapter or module, or directly on the system board.

This product guide provides essential presales information to understand the ThinkSystem M.2 offerings, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the M.2 components, and consider their use in IT solutions.

Specifications

Features

SSD capacity480 GB
SSD form factorM.2
InterfaceSerial ATA III
Component forServer/workstation
M.2 SSD size2280 (22 x 80 mm)
Data transfer rate6 Gbit/s
Read speed540 MB/s
Write speed410 MB/s
Random read (4KB)85000 IOPS
Random write (4KB)36000 IOPS
Read latency500 µs
Write latency500 µs
Hot-swapNo
TBW rating1324

Weight & dimensions

Weight10 g
