Intel Xeon E7-4820 processor 2 GHz 18 MB Smart Cache Tray
Spread the cost with Klarna, PayPal, Float or SnapFrom 3 interest-free payments of £491.33 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- Intel® Xeon® E7 Family E7-4820 2 GHz
- 18 MB Smart Cache LGA 1567 (Socket LS)
- Processor cores: 8 32 nm 64-bit 105 W
- Maximum internal memory supported by processor: 2.05 TB DDR3-SDRAM
- Tray
Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® Trusted Execution Technology
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
AES New Instructions
Advanced Encryption Standard New Instructions (AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, anthentication, random number generation, and authenticated encryption.
Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.
Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Thermal Monitoring Technologies
Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.
Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.
Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.
Specifications
Processor
| Processor ARK ID | 53675 |
|---|---|
| Processor code | SLC3G |
| Processor codename | Westmere EX |
| CPU multiplier (bus/core ratio) | 15 |
| Bus type | QPI |
| Stepping | A2 |
| Compatible chipsets | Intel® 7500 |
| Thermal Design Power (TDP) | 105 W |
| Processor cache type | Smart Cache |
| Processor cache | 18 MB |
| Processor boost frequency | 2.27 GHz |
| Processor operating modes | 64-bit |
| System bus rate | 5.86 GT/s |
| Processor threads | 16 |
| Processor series | Intel Xeon E7-4800 |
| Component for | Server/workstation |
| Cooler included | No |
| Processor lithography | 32 nm |
| Processor socket | LGA 1567 (Socket LS) |
| Processor cores | 8 |
| Processor base frequency | 2 GHz |
| Processor model | E7-4820 |
| Processor family | Intel® Xeon® E7 Family |
| Processor manufacturer | Intel |
Memory
| ECC | Yes |
|---|---|
| Memory channels | Quad-channel |
| Memory clock speeds supported by processor | 800,978,1066,1333 MHz |
| Memory types supported by processor | DDR3-SDRAM |
| Maximum internal memory supported by processor | 2.05 TB |
Show all 67 specificationsShow fewer specifications
Features
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
|---|---|
| Export Control Classification Number (ECCN) | 5A992C |
| Scalability | S4S |
| Embedded options available | No |
| CPU configuration (max) | 4 |
| Supported instruction sets | SSE4.1, SSE4.2 |
| Market segment | Server |
| Execute Disable Bit | Yes |
| Thermal Monitoring Technologies | Yes |
Processor special features
| Intel VT-x with Extended Page Tables (EPT) | Yes |
|---|---|
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 1.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
General
| Product family | Xeon |
|---|
Operational conditions
| Tcase | 64 °C |
|---|
Technical details
| Bus bandwidth | 5.86 |
|---|---|
| Bus type units | GT/s |
| Processor brand name | Intel Xeon |
| Last change | 63903513 |
| Product family | Intel Xeon Processor E7 Family |
| Launch date | Q2'11 |
| Status | Discontinued |
| Born on date | Q2'11 |
| Product name | Intel Xeon E7-4820 (18M Cache, 2.00 GHz, 5.86 GT/s Intel QPI) |
| Maximum memory | 2.05 TB |
| Bus speed | 5.86 GT/s |
| Processor cache | 18432 KB |
| Supported memory types | DDR3-SDRAM |
| Product type | Processor |
Weight & dimensions
| Processor package size | 49.17mm x 56.47mm |
|---|
Other features
| Maximum internal memory | 2097152 MB |
|---|---|
| Cache memory | 18 MB |
| Intel® Virtualization Technology (Intel® VT) | VT-x |
