Intel · MPN: AT80615006432AB
£907.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £302.66 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Intel® Xeon® E7 Family E7-4807 1.86 GHz
  • 18 MB Smart Cache LGA 1567 (Socket LS)
  • Processor cores: 6 32 nm 64-bit 95 W
  • Maximum internal memory supported by processor: 2.05 TB DDR3-SDRAM
  • Tray

Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel® Trusted Execution Technology
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

AES New Instructions
Advanced Encryption Standard New Instructions (AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, anthentication, random number generation, and authenticated encryption.

Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

Thermal Monitoring Technologies
Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limit.

Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

Specifications

Processor

Processor ARK ID53569
Processor codeSLC3L
Processor codenameWestmere EX
CPU multiplier (bus/core ratio)14
Bus typeQPI
SteppingA2
Compatible chipsetsIntel® 7500
Thermal Design Power (TDP)95 W
Processor cache typeSmart Cache
Processor cache18 MB
Processor operating modes64-bit
System bus rate4.8 GT/s
Processor threads12
Processor seriesIntel Xeon E7-4800
Component forServer/workstation
Cooler includedNo
Processor lithography32 nm
Processor socketLGA 1567 (Socket LS)
Processor cores6
Processor base frequency1.86 GHz
Processor modelE7-4807
Processor familyIntel® Xeon® E7 Family
Processor manufacturerIntel

Memory

ECCYes
Memory channelsQuad-channel
Memory clock speeds supported by processor800,978,1066,1333 MHz
Memory types supported by processorDDR3-SDRAM
Maximum internal memory supported by processor2.05 TB
Show all 66 specificationsShow fewer specifications

Features

Commodity Classification Automated Tracking System (CCATS)G077159
Export Control Classification Number (ECCN)5A992C
ScalabilityS4S
Embedded options availableNo
CPU configuration (max)4
Supported instruction setsSSE4.1, SSE4.2
Market segmentServer
Execute Disable BitYes
Thermal Monitoring TechnologiesYes

Processor special features

Intel VT-x with Extended Page Tables (EPT)Yes
Intel 64Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost TechnologyNo
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel Trusted Execution TechnologyYes
Enhanced Intel SpeedStep TechnologyYes

General

Product familyXeon

Operational conditions

Tcase70 °C

Technical details

Bus bandwidth4.8
Bus type unitsGT/s
Processor brand nameIntel Xeon
Last change63903513
Product familyIntel Xeon Processor E7 Family
Launch dateQ2'11
StatusDiscontinued
Born on dateQ2'11
Product nameIntel Xeon E7-4807 (18M Cache, 1.86 GHz, 4.80 GT/s Intel QPI)
Maximum memory2.05 TB
Bus speed4.8 GT/s
Processor cache18432 KB
Supported memory typesDDR3-SDRAM
Product typeProcessor

Weight & dimensions

Processor package size49.17mm x 56.47mm

Other features

Maximum internal memory2097152 MB
Cache memory18 MB
Intel® Virtualization Technology (Intel® VT)VT-x
