Intel · MPN: AT80614005073AB
£309.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £103.33 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Intel® Xeon® 5000 Sequence E5620 2.4 GHz
  • 12 MB Smart Cache LGA 1366 (Socket B)
  • Processor cores: 4 32 nm 64-bit 80 W
  • Maximum internal memory supported by processor: 288 GB DDR3-SDRAM
  • Tray

Designed for industry-leading performance and maximum energy efficiency, these versatile 1-way and 2-way 64-bit multi-core servers and workstations are ideally suited to a wide range of infrastructure, cloud, high-density, and high performance computing (HPC) applications.

Specifications

Processor

Processor ARK ID47925
Processor codeSLBV4
Processor codenameWestmere EP
Memory bandwidth supported by processor (max)25.6 GB/s
Number of QPI links2
CPU multiplier (bus/core ratio)18
Bus typeQPI
SteppingB1
VID Voltage Range0.75 - 1.35 V
Thermal Design Power (TDP)80 W
Processor cache typeSmart Cache
Processor cache12 MB
Processor boost frequency2.66 GHz
Processor operating modes64-bit
System bus rate5.86 GT/s
Processor threads8
Processor seriesIntel Xeon 5600 Series
Component forServer/workstation
Cooler includedNo
Processor lithography32 nm
Processor socketLGA 1366 (Socket B)
Processor cores4
Processor base frequency2.4 GHz
Processor modelE5620
Processor familyIntel® Xeon® 5000 Sequence
Processor manufacturerIntel

Memory

ECCYes
Memory channelsTriple-channel
Memory types supported by processorDDR3-SDRAM
Maximum internal memory supported by processor288 GB
Show all 73 specificationsShow fewer specifications

Graphics

On-board graphics cardNo

Features

Commodity Classification Automated Tracking System (CCATS)G077159
Export Control Classification Number (ECCN)5A992C
Embedded options availableYes
CPU configuration (max)2
Bandwidth25600 MB/s
Supported instruction setsSSE4.2
Market segmentServer
Execute Disable BitYes
Idle StatesYes
Thermal Monitoring TechnologiesNo

Processor special features

Intel VT-x with Extended Page Tables (EPT)Yes
Intel 64Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Demand Based SwitchingYes
Intel Enhanced Halt StateYes
Conflict-Free processorNo
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology1.0
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel Trusted Execution TechnologyYes
Enhanced Intel SpeedStep TechnologyYes

General

Product familyXeon

Operational conditions

Tcase77.6 °C

Technical details

Bus bandwidth5.86
Bus type unitsGT/s
Processor brand nameIntel Xeon
Last change63903513
Product familyIntel Xeon Processor 5000 Sequence
Launch dateQ1'10
StatusDiscontinued
Born on dateQ1'10
Product nameIntel Xeon E5620 (12M Cache, 2.40 GHz, 5.86 GT/s Intel QPI)
Maximum memory288 GB
Bus speed5.86 GT/s
Processor core voltage0.750-1.350 V
Processor cache12288 KB
Supported memory typesDDR3-SDRAM
Product typeProcessor

Weight & dimensions

Processor package size42.5mm x 45mm

Other features

Maximum internal memory294912 MB
Cache memory12 MB
