Intel · MPN: CM8062001122601
£529.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £176.66 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Intel® Xeon® E5 Family E5-2430 2.2 GHz
  • 15 MB Smart Cache LGA 1356 (Socket B2)
  • Processor cores: 6 32 nm 64-bit 95 W
  • Maximum internal memory supported by processor: 384 GB DDR3-SDRAM
  • Tray

Servers, workstations, and storage solutions based on the new Intel® Xeon® processor E5 family deliver the best combination of performance, built-in capabilities, and cost-effectiveness to make data centers more flexible and efficient. From virtualization and cloud computing solutions to design automation or real-time financial transactions, you’ll be delighted by better than ever performance no matter what tasks you face.

Your investment in industry standard technology from Intel combined with innovative solutions from partners help future-proof your data center with infrastructure that grows with your business.

Technology to scale innovative private cloud services
Today’s private clouds enable greater business agility and efficiency by delivering innovative and scalable services that drive value back into the organizations they serve. Building and managing these services require systems that scale to meet your ever changing needs, while delivering solutions to the challenges IT managers face every day. Server and storage platforms based on the Intel® Xeon® processor E5 family are built to be at the heart of today’s data centers and enable powerful, versatile private cloud solutions.

New Intel® Xeon® processor E5: a new performance sweet spot
The Intel® Xeon® processor E5 family support key cloud requirements that make your data center agile and more responsive to changing business needs. Maintaining industry leadership for power efficiency and continuing Intel Xeon processor performance advancements, the Intel® Xeon® processor E5 family gives you additional performance when you need it for single- and multi-threaded applications, including increased floating-point performance for technical computing workloads.

Specifications

Processor

Processor manufacturerIntel
Processor familyIntel® Xeon® E5 Family
Processor modelE5-2430
Processor base frequency2.2 GHz
Processor cores6
Processor socketLGA 1356 (Socket B2)
Processor lithography32 nm
Cooler includedNo
Component forServer/workstation
Processor seriesIntel Xeon E5-2400
Processor threads12
System bus rate7.2 GT/s
Processor operating modes64-bit
Processor boost frequency2.7 GHz
Processor cache15 MB
Processor cache typeSmart Cache
Thermal Design Power (TDP)95 W
VID Voltage Range0.6 - 1.35 V
Compatible chipsetsIntel® C602, Intel® C602J, Intel® C604, Intel® C606, Intel C608
SteppingC2
Bus typeQPI
Number of QPI links1
Memory bandwidth supported by processor (max)32 GB/s
Processor codenameSandy Bridge EN
Processor codeSR0LM
Processor ARK ID64616

Memory

Maximum internal memory supported by processor384 GB
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor800,1066,1333 MHz
Memory channelsTriple-channel
ECCYes
Show all 78 specificationsShow fewer specifications

Graphics

On-board graphics cardNo

Features

Thermal Monitoring TechnologiesYes
Idle StatesYes
Execute Disable BitYes
Market segmentServer
Maximum number of PCI Express lanes24
PCI Express slots version3.0
Supported instruction setsAVX
CPU configuration (max)2
PCI Express CEM revision3.0
Embedded options availableYes
Scalability2S
Export Control Classification Number (ECCN)5A992C
Commodity Classification Automated Tracking System (CCATS)G077159

Processor special features

Intel® Smart CacheYes
Intel Flex Memory AccessNo
Intel® Identity Protection Technology (Intel® IPT)No
Enhanced Intel SpeedStep TechnologyYes
Intel Trusted Execution TechnologyYes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Turbo Boost Technology1.0
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel Identity Protection Technology version0.00
Conflict-Free processorNo
Intel Enhanced Halt StateYes
Intel Demand Based SwitchingYes
Intel® vPro™ Platform EligibilityYes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Virtualization Technology (VT-x)Yes
Intel 64Yes
Intel VT-x with Extended Page Tables (EPT)Yes

General

Product familyXeon

Technical details

Processor cache15360 KB
Product typeProcessor
Supported memory typesDDR3-SDRAM
Product familyIntel Xeon Processor E5 Family
Last change63903513
Processor brand nameIntel Xeon
Bus type unitsGT/s
Bus bandwidth7.2
Bus speed7.2 GT/s
Maximum memory384 GB
StatusDiscontinued
Launch dateQ2'12

Weight & dimensions

Processor package size45mm x 42.5mm

Other features

Intel® Virtualization Technology (Intel® VT)VT-d, VT-x
Maximum internal memory393216 MB
