Intel FTXL710-BM1 microcontroller
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £36.66 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® Data Direct I/O Technology
Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
PCI-SIG* SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Intel® Ethernet Power Management
Intel® Ethernet Power Management Technology provides solutions to common power management approaches by reducing idle power, reducing capacity and power as a function of demand, operating at maximum energy efficiency whenever possible, and enabling functionality only when needed.
Fiber Channel over Ethernet
Fibre Channel over Ethernet (FCoE) is an encapsulation of Fibre Channel frames over Ethernet networks. This allows Fibre Channel to use 10 Gigabit Ethernet networks (or higher speeds) while preserving the Fibre Channel protocol.
IEEE 1588
IEEE 1588, also knows as the Precision Time Protocol (PTP) is a protocol used to synchronize clocks throughout a computer network. On a local area network it achieves clock accuracy in the sub-microsecond range, making it suitable for measurement and control systems.
Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance
Specifications
Features
| Product series | 700 Series Controllers (up to 40GbE) |
|---|---|
| Status | Launched |
| Product codename | Fortville |
| Storage Over Ethernet | iSCSI, NFS |
| Launch date | Q4'15 |
| Thermal Design Power (TDP) | 7 W |
| Fiber Channel over Ethernet | No |
| Jumbo frames support | Yes |
| Intelligent Offloads | Yes |
| Package size | 25 x 25 mm |
| On-chip QoS and Traffic Management | Yes |
| PCI-SIG* SR-IOV Capable | Yes |
| On-board graphics card | No |
| Lithography | 28 nm |
Processor special features
| Intel Data Direct I/O Technology | Yes |
|---|---|
| Intel Virtual Machine Device Queues (VMDq) | Yes |
| Intel Ethernet Power Management | Yes |
| Intel Flexible Port Partitioning | Yes |
Show all 26 specificationsShow fewer specifications
Ports & interfaces
| PCI Express slots version | 3.0 |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Host interface | PCI Express |
Network
| Network controller sideband interface (NC-SI) | Yes |
|---|---|
| Ethernet LAN data rates | 1000,10000,40000 Mbit/s |
Operational conditions
| Operating temperature (T-T) | 0 - 55 °C |
|---|---|
| Maximum operating temperature | 55 °C |
| Minimum operating temperature | 0 °C |
