£645.99

Stock Available: 0
  • 1 TB 2.5" PCI Express 3.1
  • Read speed: 3200 MB/s
  • Write speed: 640 MB/s
  • 3D TLC NVMe 1.2
  • Hardware encryption 256-bit AES
  • Component for: Server/workstation

This low power drive enables energy and space efficient storage solutions to help data centers do more per server, minimize service disruptions and efficiently manage at scale.

Power-Efficient, High Performance SSDs Optimized for Cloud Storage
This cloud-inspired SSD is built with an entirely new NVMe controller, optimized for read intensive workloads and designed to maximize CPU utilization. With the Intel SSD DC P4501 Series, data centers can increase users, add more services, and perform more workloads per server. Now you can store more and know more.

Optimized Solutions for Space and Power Efficiency
Available in U.2 (2.5 in x 7mm) and M.2 (110mm x 22mm) form factors, and optimized for high performance-per-watt, power efficiency, and low power envelopes, this SSD enables new opportunities to maximize storage capacity without incurring the power demands of larger, space-consuming form factors.

Outstanding Quality and Reliability
With industry-leading quality and reliability, you can be confident your drives are available and your data is protected. Support for data-at-rest encryption minimizes the likelihood of data breaches, while industry-leading end-to-end data protection reduces the chance of silent data errors.

Advanced Manageability and Serviceability
Built with advanced manageability features such as NVMe-MI, the Intel SSD DC P4501 Series allows you to remotely monitor, manage and remediate across more device states and streamline essential services.

Features
SSD ARK ID 96927
SSD usage tag Data center
Market segment Server
TBW rating 1830
Linux operating systems supported Yes
Mac operating systems supported Yes
Windows operating systems supported Yes
Mean time between failures (MTBF) 2000000 h
Uncorrectable Bit Error Rate (UBER) < 1 per 10^17 bits read
SSD temperature monitoring Yes
Enhanced Power Loss Data Protection technology Yes
End-to-End Data Protection Yes
PCI Express interface data lanes x4
Write latency 30 µs
Read latency 100 µs
Random write (100% span) 41000 IOPS
Random read (100% span) 285000 IOPS
Write speed 640 MB/s
Read speed 3200 MB/s
Security algorithms 256-bit AES
Hardware encryption Yes
Component for Server/workstation
NAND flash type TLC (Triple Level Cell)
Memory type 3D TLC
NVMe version 1.2
NVMe Yes
Interface PCI Express 3.1
SSD form factor 2.5"
SSD capacity 1 TB
Power
Power consumption (idle) 5 W
Power consumption (average) 12.5 W
Brand-specific features
Intel® Smart Response Technology No
Intel Smart Response Technology version 0.00
Intel® Remote Secure Erase No
Intel High Endurance Technology (HET) No
Intel® Rapid Start Technology No
Weight & dimensions
Weight 64 g
Height 7 mm
Operational conditions
Non-operating shock 1000 G
Operating shock 1000 G
Non-operating vibration 3.13 G
Operating vibration 2.17 G
Operating temperature (T-T) 0 - 70 °C
Other features
Product codename Cliffdale
Product series Intel® SSD DC P4501 Series
Product family Data center SSD
SSD weight 64 g
Launch date Q2'17
Drive capacity 1 TB
SSD power consumption (active) up to 10 or 12.5W
SSD shock 1000 G/0.5 msec
Last change 63903513
Intel Rapid Start Technology version 0.00
Remote Secure Erase (RSE) technology version 0.00
SSD endurance rating 1.85 PBW
Sequential reading 3100 MB/s
Sequential writing speed 620 MB/s
Status Launched
SSD hardware encryption AES 256 bit
Product colour Silver
