Intel · MPN: AT8076806772
£271.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £90.66 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Intel Core Ultra 5 225T
  • 20 MB Smart Cache LGA 1851 (Socket V1)
  • Processor cores: 10 64-bit
  • Maximum internal memory supported by processor: 256 GB DDR5-SDRAM
  • On-board graphics card Intel Graphics
  • Tray

Specifications

Processor

Processor ARK ID241870
Processor codenameArrow Lake
Maximum number of DMI lanes8
AI software frameworks supported by CPUDirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Processor base power35 W
Maximum turbo power114 W
Processor cache typeSmart Cache
Processor cache20 MB
Efficient-core base frequency1.9 GHz
Efficient-core boost frequency4.4 GHz
Performance-core base frequency2.5 GHz
Performance-core boost frequency4.9 GHz
Processor boost frequency4.9 GHz
Efficient cores4
Performance cores6
Processor operating modes64-bit
Processor threads10
Cooler includedNo
Processor socketLGA 1851 (Socket V1)
Processor cores10
Processor model225T
Processor generationIntel Core Ultra (Series 2)
Processor familyIntel Core Ultra 5
Processor manufacturerIntel

Neural processor unit (NPU)

GPU performance up to4 TOPs
NPU performance up to13 TOPs
Total processor performance up to23 TOPs
AI software frameworks supported by NPUDirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Windows Studio effects supportYes
Sparsity supportYes
Neural processor unit (NPU)Intel AI Boost
Show all 92 specificationsShow fewer specifications

Memory

Memory channelsDual-channel
Memory clock speeds supported by processor6400 MHz
Memory types supported by processorDDR5-SDRAM
Maximum internal memory supported by processor256 GB

Graphics

Xe-cores2
Discrete graphics card modelNot available
On-board graphics card ID0x7D67
On-board graphics card refresh rate at maximum resolution (DisplayPort)60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)60 Hz
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.5
Number of displays supported (on-board graphics)4
On-board graphics card dynamic frequency (max)1800 MHz
On-board graphics card base frequency300 MHz
On-board graphics card outputs supportedHDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1
On-board graphics card modelIntel Graphics
On-board graphics cardYes
Discrete graphics cardNo

Features

Scalability1S
Embedded options availableYes
Direct Media Interface (DMI) Revision4.0
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
PCI Express configurations1x16+2x4, 1x8+4x4, 2x8+2x4
PCI Express slots version4.0, 5.0
Maximum number of PCI Express lanes24
Use conditionsPC/Client/Tablet
Market segmentDesktop
Execute Disable BitYes
Idle StatesYes
Thermal Monitoring TechnologiesYes

Processor special features

Intel VT-x with Extended Page Tables (EPT)Yes
Intel 64Yes
Intel® Standard Manageability (ISM)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Volume Management Device (VMD)Yes
Mode-based Execute Control (MBE)Yes
Intel® Secure KeyYes
Intel® OS GuardYes
Intel® Boot GuardYes
Intel® Deep Learning Boost (Intel® DL Boost) on GPUYes
Intel® Thread DirectorYes
Intel® Control-flow Enforcement Technology (CET)Yes
Intel® Thunderbolt 4Yes
Intel® Turbo Boost Technology2.0
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel Trusted Execution TechnologyYes
Intel® Speed Shift TechnologyYes
Intel® Quick Sync Video TechnologyYes
Enhanced Intel SpeedStep TechnologyYes

General

Product familyCore
Product seriesUltra 5

Operational conditions

Maximum operating temperature105 °C

Technical details

Launch dateQ1'25
StatusLaunched
OpenCL version3.0

Other features

Graphics outputDP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
Maximum internal memory256 GB
L2 cache22528 KB
