Intel · MPN: AT8076806770
£180.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £60.33 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Intel Core Ultra 5 225
  • 20 MB Smart Cache LGA 1851 (Socket V1)
  • Processor cores: 10 64-bit
  • Maximum internal memory supported by processor: 192 GB DDR5-SDRAM
  • On-board graphics card Intel® Graphics
  • Tray

The latest Intel® Core™ Ultra processors (Series 2) enable you to use the most AI experiences across desktop, mobile and edge—making everything you do easier, faster, and better.

Specifications

Processor

Processor manufacturerIntel
Processor familyIntel Core Ultra 5
Processor generationIntel Core Ultra (Series 2)
Processor model225
Processor cores10
Processor socketLGA 1851 (Socket V1)
Processor threads10
Processor operating modes64-bit
Performance cores6
Efficient cores4
Processor boost frequency4.9 GHz
Performance-core boost frequency4.9 GHz
Performance-core base frequency3.3 GHz
Efficient-core boost frequency4.4 GHz
Efficient-core base frequency2.7 GHz
Processor cache20 MB
Processor cache typeSmart Cache
Maximum turbo power121 W
Processor base power65 W
AI software frameworks supported by CPUDirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Maximum number of DMI lanes8
Processor codenameArrow Lake
Processor ARK ID241070

Neural processor unit (NPU)

Neural processor unit (NPU)Intel AI Boost
Sparsity supportYes
Windows Studio effects supportYes
AI software frameworks supported by NPUDirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to23 TOPs
NPU performance up to13 TOPs
GPU performance up to4 TOPs
Show all 90 specificationsShow fewer specifications

Memory

Maximum internal memory supported by processor192 GB
Memory types supported by processorDDR5-SDRAM
Memory clock speeds supported by processor6400 MHz
Memory channelsDual-channel

Graphics

Discrete graphics cardNo
On-board graphics cardYes
On-board graphics card modelIntel® Graphics
On-board graphics card outputs supportedHDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1
On-board graphics card base frequency300 MHz
On-board graphics card dynamic frequency (max)1800 MHz
Number of displays supported (on-board graphics)4
On-board graphics card OpenGL version4.5
On-board graphics card DirectX version12.0
On-board graphics card refresh rate at maximum resolution (HDMI)60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)60 Hz
On-board graphics card ID0x7D67
Discrete graphics card modelNot available
Xe-cores2

Features

Thermal Monitoring TechnologiesYes
Idle StatesYes
Execute Disable BitYes
Market segmentDesktop
Use conditionsPC/Client/Tablet
Maximum number of PCI Express lanes24
PCI Express slots version4.0, 5.0
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Direct Media Interface (DMI) Revision4.0
Embedded options availableYes
Scalability1S

Processor special features

Intel® Quick Sync Video TechnologyYes
Enhanced Intel SpeedStep TechnologyYes
Intel® Speed Shift TechnologyYes
Intel Trusted Execution TechnologyYes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Turbo Boost Technology2.0
Intel® Thunderbolt 4Yes
Intel® Control-flow Enforcement Technology (CET)Yes
Intel® Thread DirectorYes
Intel® Deep Learning Boost (Intel® DL Boost) on GPUYes
Intel® Standard Manageability (ISM)Yes
Intel® Boot GuardYes
Intel® OS GuardYes
Intel® Secure KeyYes
Mode-based Execute Control (MBE)Yes
Intel® Volume Management Device (VMD)Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Virtualization Technology (VT-x)Yes
Intel 64Yes
Intel VT-x with Extended Page Tables (EPT)Yes

General

Product seriesUltra 5
Product familyCore

Operational conditions

Maximum operating temperature105 °C

Technical details

OpenCL version3.0
StatusLaunched
Launch dateQ1'25

Other features

L2 cache22528 KB
Maximum internal memory192 GB
Graphics outputDP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
