Intel · MPN: CM8066201919901
£139.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £46.66 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Intel® Core™ i7 i7-6700K 4 GHz
  • 8 MB Smart Cache LGA 1151 (Socket H4)
  • Processor cores: 4 14 nm 64-bit 91 W
  • Maximum internal memory supported by processor: 64 GB DDR4-SDRAM, DDR3L-SDRAM
  • On-board graphics card Intel® HD Graphics 530
  • Tray

Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

Intel® Small Business Advantage provides small businesses with out-the-box features to enhance the security and productivity of their small business with software monitor, data backup and restore, USB port blocker, health center and wireless display.

Specifications

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i7
Processor generation6th gen Intel® Core™ i7
Processor modeli7-6700K
Processor base frequency4 GHz
Processor cores4
Processor socketLGA 1151 (Socket H4)
Processor lithography14 nm
Cooler includedNo
Component forPC
Processor seriesIntel Core i7-6700 Desktop series
Processor threads8
System bus rate8 GT/s
Processor operating modes64-bit
Processor boost frequency4.2 GHz
Processor cache8 MB
Processor cache typeSmart Cache
Thermal Design Power (TDP)91 W
Compatible chipsetsIntel® B150, Intel® H110, Intel® H170, Intel® Z170, Intel Q150, Intel® Q170
SteppingR0
Bus typeDMI
Memory bandwidth supported by processor (max)34.1 GB/s
Processor codenameSkylake
Processor codeSR2BR
Processor ARK ID88195
Generation6th Generation

Memory

Maximum internal memory supported by processor64 GB
Memory types supported by processorDDR4-SDRAM, DDR3L-SDRAM
Memory clock speeds supported by processor1866,1333,2133,1600 MHz
Memory voltage supported by processor1.35 V
Memory channelsDual-channel
ECCNo
Show all 130 specificationsShow fewer specifications

Graphics

On-board graphics cardYes
On-board graphics card modelIntel® HD Graphics 530
Maximum on-board graphics card memory64 GB
On-board graphics card outputs supportedEmbedded DisplayPort (eDP), DisplayPort, HDMI, DVI
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1150 MHz
Number of displays supported (on-board graphics)3
On-board graphics card 4K supportYes
On-board graphics card OpenGL version4.5
On-board graphics card DirectX version12.0
On-board graphics card maximum resolution (HDMI)4096 x 2304 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)4096 x 2304 pixels
On-board graphics card maximum resolution (DisplayPort)4096 x 2304 pixels
On-board graphics card refresh rate at maximum resolution (HDMI)24 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)60 Hz
On-board graphics card ID1912

Features

Thermal Monitoring TechnologiesYes
Idle StatesYes
Execute Disable BitYes
Market segmentDesktop
Maximum number of PCI Express lanes16
PCI Express slots version3.0
PCI Express configurations1x16, 2x8, 1x8+2x4
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Thermal solution specificationPCG 2015D
Graphics & IMC lithography14 nm
CPU configuration (max)1
PCI Express CEM revision3.0
Embedded options availableNo
Scalability1S
Export Control Classification Number (ECCN)5A992C
Commodity Classification Automated Tracking System (CCATS)G077159

Processor special features

Intel® Insider™Yes
Intel® Wireless Display (Intel® WiDi)Yes
Intel® Memory Protection Extensions (Intel® MPX)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® InTru™ 3D TechnologyYes
Intel® Quick Sync Video TechnologyYes
Intel® Smart CacheYes
Intel® Identity Protection Technology (Intel® IPT)Yes
Enhanced Intel SpeedStep TechnologyYes
Intel Trusted Execution TechnologyNo
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Turbo Boost Technology2.0
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology 2.0 frequency4.2 GHz
Intel® Transactional Synchronization ExtensionsYes
Intel® Small Business Advantage (Intel® SBA)Yes
Intel Small Business Advantage (SBA) version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Intel Secure Key Technology version1.00
Intel Identity Protection Technology version1.00
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Yes
Intel Stable Image Platform Program (SIPP)No
Intel Clear Video TechnologyYes
Intel® Boot GuardYes
Conflict-Free processorYes
Intel TSX-NI version1.00
Intel Enhanced Halt StateYes
Intel® OS GuardYes
Intel® Secure KeyYes
Intel® vPro™ Platform EligibilityNo
Intel® Optane™ Memory ReadyNo
Intel TSX-NIYes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Virtualization Technology (VT-x)Yes
Intel 64Yes
Intel Software Guard Extensions (Intel SGX)Yes
Intel VT-x with Extended Page Tables (EPT)Yes

General

Product seriesi7
Product familyCore

Operational conditions

Tcase64 °C

Technical details

Processor cache8192 KB
Maximum graphics card memory64 GB
Product typeProcessor
Supported memory typesDDR4-SDRAM, DDR3L-SDRAM
Maximum resolution (WiDi)1080p
Number of graphics cores2
Maximum resolution & refresh rate (VGA)N/A
Product family6th Generation Intel Core i7 Processors
Last change63903513
Processor brand nameIntel Core i7
Intel Core i7 Processor
Maximum resolution & refresh rate (Integrated Flat Panel)4096x2304@60Hz
Maximum resolution & refresh rate (HDMI)4096x2304@24Hz
Bus type unitsGT/s
Bus bandwidth8
Processor ID0x1912
Bus speed8 GT/s
Maximum memory64 GB
Maximum resolution & refresh rate (DisplayPort)4096x2304@60Hz
StatusDiscontinued
Launch dateQ3'15

Weight & dimensions

Processor package size37.5 x 37.5 mm

Other features

Intel® Virtualization Technology (Intel® VT)VT-d, VT-x
Video decodingYes
Maximum internal memory65536 MB
Graphics outputeDP/DP/HDMI/DVI
