Intel · MPN: CM8071505092904
£243.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £81.33 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Intel® Core™ i5 i5-14500T
  • 24 MB Smart Cache LGA 1700
  • Processor cores: 14 64-bit
  • Maximum internal memory supported by processor: 192 GB DDR4-SDRAM, DDR5-SDRAM
  • On-board graphics card Intel UHD Graphics 770
  • Tray

Specifications

Processor

Processor ARK ID236780
Processor codenameRaptor Lake
Memory bandwidth supported by processor (max)76.8 GB/s
Maximum number of DMI lanes8
SteppingC0
Processor base power35 W
Maximum turbo power92 W
Processor cache typeSmart Cache
Processor cache24 MB
Efficient-core base frequency1.2 GHz
Efficient-core boost frequency3.4 GHz
Performance-core base frequency1.7 GHz
Performance-core boost frequency4.8 GHz
Processor boost frequency4.8 GHz
Efficient cores8
Performance cores6
Processor operating modes64-bit
Processor threads20
Processor socketLGA 1700
Processor cores14
Processor modeli5-14500T
Processor generationIntel® Core™ i5 (14th gen)
Processor familyIntel® Core™ i5
Processor manufacturerIntel

Memory

Memory bandwidth (max)76.8 GB/s
ECCYes
Memory channelsDual-channel
Memory types supported by processorDDR4-SDRAM, DDR5-SDRAM
Maximum internal memory supported by processor192 GB
Show all 104 specificationsShow fewer specifications

Graphics

Multi-Format Codec Engines2
Number of execution units32
Discrete graphics card modelNot available
On-board graphics card ID0x4680
On-board graphics card refresh rate at maximum resolution (DisplayPort)60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)60 Hz
On-board graphics card maximum resolution (DisplayPort)7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI)4096 x 2160 pixels
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.5
Number of displays supported (on-board graphics)4
On-board graphics card dynamic frequency (max)1550 MHz
On-board graphics card outputs supportedEmbedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card modelIntel UHD Graphics 770
On-board graphics cardYes
Discrete graphics cardNo

Features

Commodity Classification Automated Tracking System (CCATS)740.17B1
Export Control Classification Number (ECCN)5A992C
Scalability1S
Embedded options availableYes
Direct Media Interface (DMI) Revision4.0
CPU configuration (max)1
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
PCI Express configurations1x16+1x4, 2x8+1x4
PCI Express slots version4.0, 5.0
Maximum number of PCI Express lanes20
Use conditionsWorkstation, PC/Client/Tablet
Market segmentDesktop
Execute Disable BitYes
Idle StatesYes
Thermal Monitoring TechnologiesYes

Processor special features

Intel® Threat Detection Technology (TDT)Yes
Intel vPro® Enterprise Platform EligibilityYes
Intel® Hardware Shield EligibilityYes
Intel vPro® Essentials Platform EligibilityYes
Intel® Total Memory Encryption - Multi KeyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel® Active Management Technology (Intel® AMT)Yes
Intel 64Yes
Intel® Standard Manageability (ISM)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® One-Click RecoveryYes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Virtualization Technology with Redirect Protection (VT-rp)Yes
Intel® Volume Management Device (VMD)Yes
Mode-based Execute Control (MBE)Yes
Intel® Stable IT Platform Program (SIPP)Yes
Intel® Remote Platform Erase (RPE)Yes
Intel® Secure KeyYes
Intel® OS GuardYes
Intel® Boot GuardYes
Intel® Thread DirectorYes
Intel® Control-flow Enforcement Technology (CET)Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology2.0
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel Trusted Execution TechnologyYes
Intel® Speed Shift TechnologyYes
Intel® Quick Sync Video TechnologyYes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Enhanced Intel SpeedStep TechnologyYes

General

Product familyCore
Product seriesi5

Operational conditions

Tjunction100 °C

Technical details

Launch dateQ1'24
StatusLaunched
OpenCL version3.0

Weight & dimensions

Processor package size45 x 37.5 mm

Other features

Graphics outputeDP 1.4b, DP 1.4a, HDMI 2.1
Maximum internal memory192 GB
L2 cache11776 KB
