Intel · MPN: CM8071505093012
£155.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £51.99 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Intel® Core™ i5 i5-14400
  • 20 MB Smart Cache LGA 1700
  • Processor cores: 10 64-bit
  • Maximum internal memory supported by processor: 192 GB DDR4-SDRAM, DDR5-SDRAM
  • On-board graphics card Intel UHD Graphics 730
  • Tray

Specifications

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i5
Processor generationIntel® Core™ i5 (14th gen)
Processor modeli5-14400
Processor cores10
Processor socketLGA 1700
Processor threads16
Processor operating modes64-bit
Performance cores6
Efficient cores4
Processor boost frequency4.7 GHz
Performance-core boost frequency4.7 GHz
Performance-core base frequency2.5 GHz
Efficient-core boost frequency3.5 GHz
Efficient-core base frequency1.8 GHz
Processor cache20 MB
Processor cache typeSmart Cache
Maximum turbo power148 W
Processor base power65 W
SteppingC0
Maximum number of DMI lanes8
Memory bandwidth supported by processor (max)76.8 GB/s
Processor codenameRaptor Lake
Processor ARK ID236788

Memory

Maximum internal memory supported by processor192 GB
Memory types supported by processorDDR4-SDRAM, DDR5-SDRAM
Memory channelsDual-channel
Memory bandwidth (max)76.8 GB/s
Show all 92 specificationsShow fewer specifications

Graphics

Discrete graphics cardNo
On-board graphics cardYes
On-board graphics card modelIntel UHD Graphics 730
On-board graphics card outputs supportedEmbedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card dynamic frequency (max)1550 MHz
Number of displays supported (on-board graphics)4
On-board graphics card OpenGL version4.5
On-board graphics card DirectX version12.0
On-board graphics card maximum resolution (HDMI)4096 x 2160 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)5120 x 3200 pixels
On-board graphics card maximum resolution (DisplayPort)7680 x 4320 pixels
On-board graphics card refresh rate at maximum resolution (HDMI)60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)120 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)60 Hz
On-board graphics card ID0x4682/0xA782
Discrete graphics card modelNot available
Number of execution units24
Multi-Format Codec Engines1

Features

Thermal Monitoring TechnologiesYes
Idle StatesYes
Execute Disable BitYes
Market segmentDesktop
Use conditionsPC/Client/Tablet
Maximum number of PCI Express lanes20
PCI Express slots version4.0, 5.0
PCI Express configurations1x16+1x4, 2x8+1x4
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Direct Media Interface (DMI) Revision4.0
CPU configuration (max)1
Embedded options availableYes
Scalability1S
Export Control Classification Number (ECCN)5A992C
Commodity Classification Automated Tracking System (CCATS)740.17B1

Processor special features

Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Quick Sync Video TechnologyYes
Enhanced Intel SpeedStep TechnologyYes
Intel® Speed Shift TechnologyYes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Turbo Boost Technology2.0
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0Yes
Intel® Control-flow Enforcement Technology (CET)Yes
Intel® Thread DirectorYes
Intel® Standard Manageability (ISM)Yes
Intel® Boot GuardYes
Intel® OS GuardYes
Intel® Secure KeyYes
Mode-based Execute Control (MBE)Yes
Intel® Volume Management Device (VMD)Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Virtualization Technology (VT-x)Yes
Intel 64Yes
Intel VT-x with Extended Page Tables (EPT)Yes

General

Product seriesi5
Product familyCore

Operational conditions

Tjunction100 °C

Technical details

OpenCL version3.0
StatusLaunched
Launch dateQ1'24

Weight & dimensions

Processor package size45 x 37.5 mm

Other features

L2 cache9728 KB
Maximum internal memory192 GB
Graphics outputeDP 1.4b, DP 1.4a, HDMI 2.1
