Intel · MPN: CM8071505163800
£129.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £43.33 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Intel® Celeron® 7305L 1.1 GHz
  • 8 MB Smart Cache LGA 1700
  • Processor cores: 5 64-bit 15 W
  • Maximum internal memory supported by processor: 64 GB LPDDR4x-SDRAM, DDR4-SDRAM, LPDDR5-SDRAM, DDR5-SDRAM
  • On-board graphics card Intel® UHD Graphics
  • Tray

Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Cache
CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.

Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Max Turbo Frequency
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.

Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Instruction Set
An instruction set refers to the basic set of commands and instructions that a microprocessor understands and can carry out. The value shown represents which Intel’s instruction set this processor is compatible with.

Intel® Quick Sync Video
Intel® Quick Sync Video delivers fast conversion of video for portable media players, online sharing, and video editing and authoring.

Intel® Wake on Voice
Intel® Wake on Voice allows your device to wait and listen for your command without consuming excessive power and battery life, as well as wake from modern standby.

Intel® Thunderbolt™ 4
Universal computer port that can dynamically adjust data and video bandwidth depending on the device and/or application.

Intel® Adaptix™ Technology
Intel® Adaptix™ Technology is a collection of software tools used to tune the system for maximum performance and customize advanced system settings for such things as overclocking and graphics. These software tools help the system adapt these settings to its environment, utilizing machine learning algorithms and advanced power control settings.

Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

Intel® Flex Memory Access
Intel® Flex Memory Access facilitates easier upgrades by allowing different memory sizes to be populated and remain in dual-channel mode.

Secure Key
Intel® Secure Key consists of a digital random number generator that creates truly random numbers to strengthen encryption algorithms.

Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Instruction Set Extensions
Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).

Intel® High Definition Audio
Audio interface for codecs to communicate with Intel SoCs and chipsets.

Intel® Smart Sound Technology
Intel® Smart Sound Technology is an integrated audio DSP (Digital Signal Processor) built to handle audio, voice, and speech interaction. It allows the latest Intel® Core™ processor-based PCs to respond to your voice command quickly and offer high fidelity audio without impact system performance and battery life.

Intel® Image Processing Unit
Intel® Image Processing Unit is an integrated image signal processor with advanced hardware implementation that improves image and video quality of cameras.

Thermal Monitoring Technologies
Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.

Intel® Volume Management Device (VMD)
Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Mode-based Execute Control (MBEC)
Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.

Intel® Boot Guard
Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.

Intel® Control-Flow Enforcement Technology
CET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.

Specifications

Processor

Processor ARK ID230903
Processor codenameAlder Lake
SteppingR0
Minimum Assured Power12 W
Maximum Assured Power28 W
Processor base power15 W
Configurable TDP-down12 W
Thermal Design Power (TDP)15 W
Processor cache typeSmart Cache
Processor cache8 MB
Performance-core boost frequency1.1 GHz
Processor boost frequency1.1 GHz
Efficient cores4
Performance cores1
Processor operating modes64-bit
Processor threads5
Processor socketLGA 1700
Processor cores5
Processor base frequency1.1 GHz
Processor model7305L
Processor familyIntel® Celeron®
Processor manufacturerIntel

Memory

ECCNo
Memory channelsDual-channel
Memory types supported by processorLPDDR4x-SDRAM, DDR4-SDRAM, LPDDR5-SDRAM, DDR5-SDRAM
Maximum internal memory supported by processor64 GB
Show all 92 specificationsShow fewer specifications

Graphics

Multi-Format Codec Engines2
Number of execution units48
Discrete graphics card modelNot available
On-board graphics card ID0x46B3
On-board graphics card refresh rate at maximum resolution (DisplayPort)60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)60 Hz
On-board graphics card maximum resolution (DisplayPort)7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)4096 x 2304 pixels
On-board graphics card maximum resolution (HDMI)4096 x 2304 pixels
On-board graphics card DirectX version12.1
On-board graphics card OpenGL version4.6
Number of displays supported (on-board graphics)4
On-board graphics card dynamic frequency (max)1100 MHz
On-board graphics card outputs supportedEmbedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card modelIntel® UHD Graphics
On-board graphics cardYes
Discrete graphics cardNo

Features

Commodity Classification Automated Tracking System (CCATS)G167599
Export Control Classification Number (ECCN)5A992C
Embedded options availableYes
CPU configuration (max)1
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
PCI Express slots version4.0
Maximum number of PCI Express lanes20
Use conditionsPC/Client/Tablet
Market segmentEmbedded
Execute Disable BitYes
Thermal Monitoring TechnologiesYes

Processor special features

Intel® Threat Detection Technology (TDT)Yes
Intel® QuickAssist Software AccelerationYes
MIPI SoundWire1.2
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Volume Management Device (VMD)Yes
Mode-based Execute Control (MBE)Yes
Intel® Secure KeyYes
Intel® OS GuardYes
Intel® vPro™ Platform EligibilityNo
Intel® Boot GuardYes
Intel® High Definition Audio (Intel® HD Audio)Yes
Intel® Smart Sound TechnologyYes
Chipset / PCH PCIe RevisionGen 3
Intel® Thread DirectorYes
Intel® Control-flow Enforcement Technology (CET)Yes
Intel® Adaptix TechnologyYes
Intel® Image Processing Unit6.0
Intel® Wake on VoiceYes
Intel® Thunderbolt 4Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0Yes
Intel® Hyper Threading Technology (Intel® HT Technology)No
Intel® Turbo Boost TechnologyNo
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Speed Shift TechnologyYes
Intel® Quick Sync Video TechnologyYes
Intel Flex Memory AccessYes

General

Product familyCeleron

Operational conditions

Tjunction100 °C

Technical details

Launch dateQ3'22
StatusLaunched
OpenCL version3.0

Weight & dimensions

Processor package size50 x 25 mm

Other features

Graphics outputeDP 1.4b, DP 1.4a, HDMI 2.1
Maximum internal memory64 GB
