Overview

  • Managed SNMP 1, SNMP 3, SMI-S, SSH-2, CLI
  • Quality of Service (QoS) support
  • Fiber
  • Access Control List (ACL)
  • 2U Rack mounting
  • Power supply included

Are you looking to modernize your storage network?

The all-flash data center and emerging NVMe storage requires a modern storage network that can keep up with pace of innovation seen with compute and storage resources. The HPE C-series SN6630C 96-port 32Gb Fibre Channel (FC) Switch is the next generation 96-port 2-rack unit FC switch that provides high-speed Fibre Channel connectivity in the SAN. This switch offers state-of-art analytics and telemetry capability built into its next-generation Application-Specific Integrated Circuit (ASIC) platform. The Non-Volatile Memory express (NVMe)-ready switch allows a seamless transition to Fibre Channel Non-Volatile Memory Express (FC-NVMe) workloads whenever available without any hardware upgrade in the SAN. This high-density, highly reliable, and scalable, enterprise-class switch is ideal for medium to large departmental SANs.

Features

High-speed Flash-ready Performance
- HPE C-series SN6630C Fibre Channel Switch with centralized non-blocking arbitration, provides consistent 32 Gbps low-latency performance across traffic conditions for every Fibre Channel port on the switch.
- Delivers increased performance with an aggregate bandwidth of 3 Tbps for growing and dynamic workloads.
- It offers state-of-the-art SAN Insights (analytics) and telemetry capabilities that have been built into this next-generation hardware platform.
- FC-NVMe-ready SAN switch with enhanced buffer-to-buffer (B2B) credits connecting both storage and host ports and FC link encryption.

More Flexibility
- HPE C-series SN6630C Fibre Channel Switch provides an option to deploy as few as 48 32-Gbps FC ports in the entry-level variant, and then grow in increments of 16 ports to up to 96 ports. This allows four possible configurations of 48, 64, 80, and 96 ports.
- The 32 Gbps ports allow users to deploy them on existing 16 or 8 Gbps transceivers, reducing initial CapEx and investment protection with an option to upgrade to 32 Gbps transceivers and adapters whenever needed.
- Increased fabric scalability provides more flexibility for a variety of SAN architectures.

Easy Manageability
- HPE C-series SN6630C Fibre Channel Switch supports enhanced diagnostic features such as inter-switch link (ISL) and host-bus-adapter (HBA) diagnostics, read diagnostic parameters, link cable beacon, and advanced reliability features such as forward error correction (FEC) with HBA ports.
- Cisco Data Center Network Manager Essentials Edition software, included with the switch, provides a centralized management tool with task-based wizards that simplifies management of switches and fabrics. Additional advanced features are available with the DCNM licensed version, sold separately.
- Cisco SAN Insights delivers deep visibility into I/O traffic between the compute and the storage infrastructure. This information is in addition to the already-available visibility obtained from individual ports, switches, servers, virtual machines, and storage arrays.

Intelligent Network Services for SAN
- HPE C-series SN6630C Fibre Channel Switch supports slow-drain detection and isolation, virtual SAN (vSAN) technology, access control lists for hardware-based intelligent frame processing, smart zoning, and other various services.
- Provides visibility into all virtual machines that are accessing the storage LUNs in the fabric and offers an end-to-end view for analytics.
- Delivers powerful representational state transfer (REST) and NX-API capabilities to enable flexible and rapid programming of utilities for the SAN.

Specifications

Management features

Quality of Service (QoS) supportYes
Switch typeManaged

Ports & interfaces

Fiber optic connectorSFP
Fiber ports quantity48
SFP module slots quantity96
Basic switching RJ-45 Ethernet ports typeNo
Show all 29 specificationsShow fewer specifications

Network

Cable types supportedFiber

Data transmission

Switching capacity0 Gbit/s
MAC address table0 entries

Security

Security algorithms256-bit AES
Authentication typeRADIUS
SSH/SSL supportYes
Access Control List (ACL)Yes

Protocols

Management protocolsSNMP 1, SNMP 3, SMI-S, SSH-2, CLI

Design

Product colourGrey
Form factor2U
Rack mountingYes

Power

AC input frequency50 - 60 Hz
Number of power supply units2
Redundant power supply (RPS) supportYes
Power supply includedYes

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating relative humidity (H-H)10 - 90%
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C

Weight & dimensions

Weight18.9 kg
Height86.1 mm
Depth565.9 mm
Width442.5 mm
