HPE Aruba Networking Networking Instant On Indoor Access Point 2x2 Wi-Fi 6 (JP) AP22
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £70.99 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- 2.4 GHz 574 Mbit/s
- 5 GHz 1200 Mbit/s
- Maximum data transfer rate: 1774 Mbit/s
- IEEE 802.11ax
- WPA2, WPA3
- Power over Ethernet (PoE)
- Internal
HPE Networking Instant On Access Points AP22 delivers affordable, business-grade 802.11ax Wi-Fi for high performance, high density small business environments. Business-grade capabilities are designed to meet the growing number of mobile, IoT, and security needs. The compact form factor of the AP22 delivers multi-user capabilities and a maximum aggregate peak data rate of 1.2 Gbps for high-definition video streaming and cloud application requirements. Everything from mounting hardware to easy-to-use web and mobile app management tools, and business-grade software features are included; no extra charge or need for external controllers.
What is new supporting point:
Wi-Fi 6 for high performance and efficiency
Supports up to 75 associated clients
Support for WPA2/WPA3 protected employee and guest login with Enhanced Open for per user guest access
Specifications
Features
| Modulation | 256-QAM, 1024-QAM |
|---|---|
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Bluetooth | Yes |
| Networking standards | IEEE 802.11ax |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1200 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer rate | 1774 Mbit/s |
| 5 GHz | Yes |
| 2.4 GHz | Yes |
Security
| Security algorithms | WPA2, WPA3 |
|---|
Show all 29 specificationsShow fewer specifications
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
|---|
Power
| Power consumption (max) | 10.1 W |
|---|---|
| Power over Ethernet (PoE) | Yes |
Design
| Cable lock slot type | Kensington |
|---|---|
| Cable lock slot | Yes |
| Product colour | White |
| Placement | Ceiling, Wall |
Antenna
| Antenna gain level (max) | 5.6 dBi |
|---|---|
| Antenna direction type | Omni-directional |
| Antenna type | Internal |
General
| Product family | Aruba Networking |
|---|
Certificates
| Certification | None |
|---|
Weight & dimensions
| Weight | 500 g |
|---|---|
| Height | 37 mm |
| Depth | 160 mm |
| Width | 160 mm |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
