Epson EB-685W
£1,166.99
Couldn't load pickup availability
- Up to 100-inch display and outstanding quality: HD-ready WXGA resolution with Epson 3LCD technology
- Reliable: Improved reliability and a longer lamp life
- Wireless Connectivity (Optional): Allows content to be shown from a range of devices
- Long lamp life: Up to 10,000 hours in eco mode
- Ultra short throw projection: For maximum installation flexibility
HD-ready classroom projector
The EB-685W's ultra-short-throw design allows you to present large images from a very short distance with minimised shadows and glare. With a brightness level of 3,500 lumens, an HD-ready WXGA resolution, a 14,000:1 contrast ratio, and HDMI input, students benefit from sharp, clear images.
High-quality, bright images
Epson’s 3LCD technology ensures high-quality images with equally high White and Colour Light Output for vivid colours and bright images, even in daylight, and three times brighter colours than leading competitive projectors{s1.
Keep costs down
Project for longer with improved reliability and a longer lamp life of up to 10,000 hours in eco mode.
Enhanced learning
Split-screen functionality allows two pieces of content to be displayed simultaneously without compromising on quality. The moderator function allows teachers to remain in control, choosing what content to display.
Optional wireless capability
Wirelessly display content easily from a range of smart devices and Google Chromebooks using our iProjection App{s2.
Document camera compatibility
Connecting the optional Epson document camera allows you to easily display images and 3D objects with incredible detail for the whole class to see.
| Projector | |
|---|---|
| Projector brightness | 3500 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WXGA (1280x800) |
| Contrast ratio (typical) | 300:1 |
| Native aspect ratio | 16:10 |
| Supported aspect ratios | 16:10 |
| Screen size compatibility | 1524 - 2540 mm (60 - 100") |
| Projection distance | 0.4 - 0.6 m |
| Projection distance (wide) | 0 - 0.4 m |
| Projection distance (tele) | 0 - 0.6 m |
| Contrast ratio (dynamic) | 14000:1 |
| Number of colours | 1.07 billion colours |
| Projector brightness (economic mode) | 2900 ANSI lumens |
| Vertical scan range | 100 - 120 Hz |
| Matrix size | 1.5 cm (0.59") |
| Keystone correction, vertical | ±3° |
| Keystone correction, horizontal | ±3° |
| Light source | |
|---|---|
| Light source type | Lamp |
| Service life of light source | 5000 h |
| Service life of light source (economic mode) | 10000 h |
| Lamp power | 250 W |
| Lens system | |
|---|---|
| Focus | Manual |
| Focal length range | 3.7 mm |
| F-number (relative aperture) | 1.6 |
| Zoom capability | Yes |
| Zoom ratio | 1.35:1 |
| Digital zoom | 1.35x |
| Throw ratio | 0.28 - 0.37:1 |
| Video | |
|---|---|
| Full HD | No |
| HD-Ready | Yes |
| 3D | No |
| Video colour modes | Blackboard, Dynamic, Presentation, Sports, sRGB, Theatre, Whiteboard |
| Colour modes (2D) | Cinema, Dynamic |
| Video processing | 10 bit |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 3 |
| HDMI ports quantity | 3 |
| DVI port | No |
| Composite video in | 1 |
| USB 2.0 ports quantity | 2 |
| Audio (L/R) in | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Serial interface type | RS-232 |
| USB connector type | USB Type-A, USB Type-B |
| Mobile High-Definition Link (MHL) | Yes |
| AC (power) in | Yes |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Storage | |
|---|---|
| Card reader integrated | No |
| Features | |
|---|---|
| Noise level | 35 dB |
| Noise level (economic mode) | 30 dB |
| On Screen Display (OSD) | Yes |
| Air filter | Yes |
| Country of origin | Philippines |
| Password protection | Yes |
| Compatible operating systems | Linux, Mac OS 10.10.x, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04 LTS, Windows 10, Windows 8, Windows 8.1 |
| Multimedia | |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 16 W |
| Design | |
|---|---|
| Product type | Ultra short throw projector |
| Product colour | Grey, White |
| Placement | Wall |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Display | |
|---|---|
| Built-in display | No |
| Power | |
|---|---|
| Power source | AC |
| Power consumption (typical) | 354 W |
| Power consumption (standby) | 0.39 W |
| Power consumption (PowerSave) | 310 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Software | |
|---|---|
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Mac compatibility | Yes |
| Mac operating systems supported | Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
|---|---|
| Weight | 5.7 kg |
| Width | 367 mm |
| Depth | 400 mm |
| Height | 149 mm |
| Package width | 490 mm |
| Package depth | 730 mm |
| Package height | 335 mm |
| Package weight | 18.5 kg |
| Packaging content | |
|---|---|
| Remote control included | Yes |
| Remote control type | IR |
| Batteries included | Yes |
| Manual | Yes |
| Cables included | USB |
| Bundled software | EasyMP Multi PC Projection, Epson Projector Management |
| Technical details | |
|---|---|
| Mobile app support | Yes |
| Other features | Auto brightness adjustment, Automatic input selection, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Dynamic lamp control, Easy OSD pre-setting, Home Screen, Long lamp life, Split-Screen-Function, Wireless LAN capable |
| USB display function | 3 in 1: Image / Mouse / Sound |
| Logistics data | |
|---|---|
| Quantity per pack | 1 pc(s) |
| Pallet height (UK) | 141 cm |
| Pallet width (UK) | 100 cm |
| Pallet length (UK) | 120 cm |
| Products per pallet (UK) | 12 pc(s) |
| Products per pallet layer (UK) | 2 pc(s) |
| Products per pallet layer | 2 pc(s) |
| Pallet gross height | 141 cm |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Products per pallet | 12 pc(s) |
| Other features | |
|---|---|
| Interface | USB 2.0-A, USB 2.0, RS-232C, HDMI in (3x), Composite in, RGB in (2x), RGB out, Jack plug out, Jack plug in (3x), Microphone input, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11b/g/n (optional), VGA in (2x), VGA out, MHL |
| Security features | Kensington lock, Password lock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection |
| RS-232 ports | 1 |
| Option type | Air filter ELPAF38, Connection and control box, Document camera, External Speaker, USB extension cable, Wireless LAN unit |
| Box contents | Installation/safety manual, Main unit, Power cable, Projector feet, Quick Start Guide, Remote control incl. batteries, Safety wire set, Template Sheet, Wall hanging bracket |
| Control panel | 0.59 inch with D9 |
