DrayTek VigorAP 805 Mesh AX3000 Wireless Access Point, 2.5GbE Uplink, additional 1GbE for Wired Connectivity, Cylinder Form-factor
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £31.99 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
In stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Overview
- Wi-Fi 6 Mesh Wireless Access Point
- AX3000 – 11ax Dual Band Wireless
- WPA3 Security – Stronger Security with WPA3 Personal & Enterprise
- Power through DC Power Adapter (included)
- Multi-SSID over Mesh – Separate Internal and Guest Networks over Mesh*
- 2.5Gb Ethernet Uplink & Additional GbE interface
- Centrally Managed or Standalone Operation
- Root AP for AP Management
The VigorAP 805 is a high-performance Mesh Wireless Access Point. It offers up to 3Gbps dual-band wireless performance and up to 2.5Gb Ethernet connectivity. The second Gigabit Ethernet port can be used as a mini switch to connect a computer or printer.
Specifications
Features
| 2.4 GHz | Yes |
|---|---|
| 6 GHz | No |
| 5 GHz | Yes |
| Maximum data transfer rate | 3000 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 2400 Mbit/s |
| Maximum data transfer rate (5 GHz) | 600 Mbit/s |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Number of simultaneously connected devices (max) | 256 |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Number of users | 256 user(s) |
| Automatic channel selection | Yes |
| Full duplex | Yes |
| MIMO | Yes |
| Spatial streams | 2 |
| MIMO type | Multi User MIMO |
| Spread spectrum method | OFDMA |
| Fit AP mode features | 802.11k & 802.11v smart roaming, Mesh networking, WDS zero-configuration deployment, Wireless distribution system (WDS) |
| Wi-Fi roaming | Yes |
| Fast roaming | Yes |
| VLAN support | Yes |
| Wireless isolation | Yes |
| Smart mesh system | Yes |
| Band steering | Yes |
| Airtime Fairness (ATF) | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Quality of Service (QoS) support | No |
| Cloud services supported | Draytek VigorACS |
| BeamForming | Yes |
Security
| Security algorithms | SNMP, SNMPv2, SNMPv3, SSH, SSID, WPA, WPA2, WPA2-Enterprise, WPA2-Personal, WPA3, WPA3-Enterprise, WPS |
|---|---|
| MAC address filtering | Yes |
| Service Set Identifier (SSID) features | Hidden SSID, Multiple SSIDs, SSID broadcast, SSID broadcast on/off |
| Number of SSID supported | 16 |
| Auto Wireless Distribution System (WDS) | Yes |
| Access Control List (ACL) | Yes |
Show all 74 specificationsShow fewer specifications
Protocols
| DHCP server | Yes |
|---|---|
| DHCP client | Yes |
| Management protocols | TR-069 |
| IPv4 & IPv6 features | Dual stack IPv4/IPv6 |
Management features
| Web-based management | Yes |
|---|---|
| Local AP management | Telnet |
| Command-line interface (CLI) | Yes |
| Syslog | Yes |
| Management platform | Draytek vigorACS |
| Batch upgrade | Yes |
| Firmware upgradeable | Yes |
Ports & interfaces
| Interface | 2 |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
Power
| Power over Ethernet (PoE) | No |
|---|---|
| Power consumption (max) | 12 W |
Design
| Placement | Desk, Table, Shelf |
|---|---|
| Product colour | White |
| Housing material | Plastic |
| Reset button | Yes |
| LED indicators | LAN, System |
Antenna
| Antenna type | Internal |
|---|---|
| Antenna direction type | Omni-directional |
| Antennas quantity | 5 |
| Antenna gain level (max) | 4.9 dBi |
Performance
| Operating system installed | DrayOS |
|---|
Certificates
| PSTI certified | Yes |
|---|---|
| Compliance certificates | CE, UKCA |
Weight & dimensions
| Width | 110 mm |
|---|---|
| Depth | 110 mm |
| Height | 153 mm |
| Weight | 405 g |
Packaging content
| Quantity per pack | 1 pc(s) |
|---|---|
| AC adapter included | Yes |
| Cables included | LAN (RJ-45) |
| Quick start guide | Yes |
Other features
| Rack mounting | No |
|---|
Operational conditions
| Operating relative humidity (H-H) | 10 - 90% |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
