Digitus Modular patch panel, 24-port
Digitus Modular patch panel, 24-port
Digitus Modular patch panel, 24-port
Digitus Modular patch panel, 24-port

Digitus Modular patch panel, 24-port

Digitus

iFrame
×
£18.99
Stock Available: 56
  • Keystone mount version: Straight
  • Application areas: 483 mm (19") distribution cabinet
  • Standards: ISO/IEC 11801 3rd Ed., EN 50173-1, EIA/TIA 568-C.2
  • General properties:
  • Suitable for 483 mm (19") rack mounting
  • Suitable for shielded Digitus® Keystone modules and connectors
  • Central earthing connection
  • Technical features:
  • Housing material: 1.5 mm SPCC cold-rolled sheet steel, powder-coated
  • Material standard: EN 10 130(1991), BS 1449, NFA 36/401, DIN 1623, UNI 5866, UNE 36-086, SIS, JIS G 3141, ASTM, SAE, NFA 36/401
  • Material earthing bar: galvanized steel
  • Physical properties:
  • Operating temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
  • Color: Black RAL9005

The modular patch panel from DIGITUS® is available as a 16- or 24-port version. The 1.5 mm cold-rolled carbon steel provides optimum support for your Keystone modules.

Network
Ports quantity 24
Design
Product colour Black
Mounting Rack mounting
Rack capacity 1U
Weight & dimensions
Width 483 mm
Depth 1.5 mm
Packaging data
Package width 560 mm
Package depth 75 mm
Package weight 873.333 g
Package volume 4200 cm³
Logistics data
Country of origin China
Harmonized System (HS) code 85371098
UK Trade Tariff code 83024900
