DELL
£10,771.99
Stock Available: 0
  • No OS
  • Intel Xeon 6 6517P (72MB Cache, 3.2GHz)
  • 32GB DDR5-SDRAM (1 x 32) & 1920GB SSD
  • iDRAC10, Enterprise 17G

Simple, Scalable and Efficient Solutions
The Dell PowerEdge R570 is a 2U, one-socket rack server engineered for high-performance computing with exceptional power efficiency and balanced performance, driving cost savings and boosting data center productivity.

Processor
Processor threads 32
Memory types supported by processor DDR5-SDRAM
Memory clock speeds supported by processor 6400 MHz
System bus rate 24 GT/s
Thermal Design Power (TDP) 190 W
Number of processors installed 1
Processor cache 72 MB
Processor cores 16
Processor boost frequency 4.2 GHz
Processor frequency 3.2 GHz
Processor model 6517P
Processor family Intel Xeon 6
Processor manufacturer Intel
Memory
Maximum internal memory 1 TB
Memory data transfer rate 6400 MT/s
Memory slots 16x DIMM
Memory layout (slots x size) 1 x 32 GB
Memory ranking 2
Buffered memory type Registered (buffered)
Internal memory type DDR5-SDRAM
Internal memory 32 GB
Storage
Drive writes per day (DWPD) 1
Optical drive type No
Hot-Plug support Yes
Supported RAID controllers PERC H965i Controller, Front, DC-MHS
RAID support Yes
Number of SSDs supported 16
SSD size 2.5"
Supported SSD sizes 2.5"
SSD interface SATA III
SSD capacity 960 GB
Number of SSDs installed 2
Total storage capacity 1.92 TB
Ports & interfaces
VGA (D-Sub) ports quantity 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3
USB 2.0 ports quantity 1
Ethernet LAN (RJ-45) ports 2
Expansion slots
PCI Express x16 (Gen 5.x) slots 2
Design
Bezel Yes
Product colour Black
Chassis type Rack (2U)
Performance
Remote administration iDRAC10, Enterprise 17G
Software
Compatible operating systems Canonical Ubuntu Server LTS RedHat Enterprise LinuxSUSE Linux Enterprise ServerVMware ESXiWindows ServerWindows Server Datacenter
Operating system installed No
Power
Power supply input voltage 100 - 240 V
Number of redundant power supplies installed 2
Power supply 1100 W
Redundant power supply (RPS) support Yes
Certificates
80 PLUS certification 80 PLUS Titanium
Carbon footprint
Total carbon footprint (kg of CO2e) 1247
Total carbon emissions, standard deviation (kg of CO2e) 101
Carbon emissions, manufacturing (kg of CO2e) 463.884
Carbon emissions, logistics (kg of CO2e) 209.496
Carbon emissions, energy usage (kg of CO2e) 537.457
Carbon emissions, end-of-life (kg of CO2e) 37.41
PAIA version PAIA 1.4.7, 2025
Weight & dimensions
Height 86.8 mm
Width 482 mm
Packaging content
Packaging content 2x Rack Power Cord 2M (C13/C14 12A) - FGA Only2U Combo Drop-In/Stab-In Rails,Riser Config 5
Other features
Open Compute Project (OCP) 1x16 FLOP, 1x16 Onboard, 1 Rear Blank
Target workload Read Intensive (RI)
Data transfer rate 6 Gbit/s
Bytes per sector 512e
