Cooler Master MasterFrame 600 Mesh Midi Tower Black
Couldn't load pickup availability
- Rear SickleFlow 120 ARGB PWM Fans,
- Front Dual SickleFlow 200 ARGB PWM Fan,
- Triple 360mm Radiator support,
- Tempered Glass side,
- USB 3.2 Type-C
Premium modular ATX case
MasterFrame 600 Mesh
Premium open-frame ATX case designed for modular builds, extreme cooling, and total customization through the FreeForm 2.0 platform.
MasterFrame 600 Mesh
The MasterFrame 600 Mesh is a premium open-frame mid-tower chassis built for high-performance hardware, extreme cooling, and total customization. Designed with FreeForm 2.0 in mind, it supports ATX to E-ATX motherboards and offers full access to modular design files, empowering users to build and evolve without limits.
FreeForm 2.0
Exo-structure
The exposed frame structure enhances chassis adaptability and provides flexible configuration options for various scenarios.
Flexible Motherboard Support
Supports Mini-ITX to E-ATX motherboards, offering compatibility with a wide range of builds and configurations.
Versatile & Maker-Driven
Its open source design and interchangeable panels offer endless personalization possibilities, transforming your chassis into a unique expression of style.
Extensive Cooling Support
Can house up to eleven fans and multiple radiator sizes (up to 420mm), ensuring superior thermal performance.
Ample GPU Clearance
Accommodates graphics cards up to 485mm, offering plenty of space for high-end GPUs.
Included GPU support bracket
The included GPU support bracket prevents GPU sag and ensures stability during intense gaming or high-performance workloads, maintaining a clean and secure build.
Tool-Free Panel Removal
Easily remove side panels and other components without tools for quick access and modifications during build or upgrades.
| Design | |
|---|---|
| Maximum PSU length | 23.5 cm |
| Maximum graphics card length | 48.5 cm |
| Maximum CPU cooler height | 19 cm |
| LED indicators | Yes |
| On/off button | Yes |
| Cable management | Yes |
| Anti-dust filter | Yes |
| Tempered glass panel(s) | Yes |
| Illumination location | Case fans |
| Illumination colour | Multi |
| Illumination | Yes |
| Suitable for | Gaming |
| Side window | Yes |
| Number of expansion slots | 8 |
| Number of internal 3.5" bays | 2 |
| Number of 2.5" bays | 3 |
| Number of 3.5" bays | 2 |
| Supported motherboard form factors | ATX, EATX, ITX, micro ATX, Mini-DTX, Mini-ITX, SSI CEB |
| Product colour | Black |
| Material | Aluminium, SGCC, Tempered glass |
| Type | PC |
| Form factor | Midi Tower |
| Power supply | |
|---|---|
| Supported power supply form factors | ATX |
| Power supply location | Bottom |
| Power supply included | No |
| Ports & interfaces | |
|---|---|
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Cooling | |
|---|---|
| Pulse-width modulation (PWM) support | Yes |
| Top radiator sizes supported | 120,140,240,280,360,420 mm |
| Rear radiator sizes supported | 120 mm |
| Side radiator sizes supported | 240,280,360,420 mm |
| Front radiator sizes supported | 120,140,240,280,360,420 mm |
| Liquid cooling capability | Yes |
| Top fans diameters supported | 120,140,180,200 mm |
| Number of top fans supported (max) | 3 |
| Rear fans diameters supported | 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans installed | 1x 120 mm |
| Side fans diameters supported | 120,140 mm |
| Number of side fans supported (max) | 3 |
| Front fans diameters supported | 120,140,180,200 mm |
| Number of front fans supported (max) | 3 |
| Front fans installed | 2x 200 mm |
| Storage | |
|---|---|
| HDD/SSD combo cage | Yes |
| Supported HDD sizes | 2.5,3.5" |
| Technical details | |
|---|---|
| Warranty period | 2 year(s) |
| Weight & dimensions | |
|---|---|
| Weight | 12 kg |
| Height | 544 mm |
| Depth | 531 mm |
| Width | 261 mm |
| Packaging data | |
|---|---|
| Package weight | 15 kg |
| Other features | |
|---|---|
| Volume | 73.6 L |
