Cisco Intel Xeon Silver 4210R processor 2.4 GHz 13.75 MB
£1,004.99
Couldn't load pickup availability
- Intel Xeon Silver 4210R 2.4 GHz
- 13.75 MB LGA 3647 (Socket P)
- Processor cores: 10 14 nm 64-bit 100 W
- Maximum internal memory supported by processor: 1.02 TB DDR4-SDRAM
The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.
| Processor | |
|---|---|
| Processor codename | Cascade Lake |
| Thermal Design Power (TDP) | 100 W |
| Processor cache | 13.75 MB |
| Processor boost frequency | 3.2 GHz |
| Processor operating modes | 64-bit |
| Processor threads | 20 |
| Processor series | Intel Xeon Silver 4000 Series |
| Component for | Server/workstation |
| Cooler included | No |
| Processor lithography | 14 nm |
| Processor socket | LGA 3647 (Socket P) |
| Processor cores | 10 |
| Processor base frequency | 2.4 GHz |
| Processor model | 4210R |
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Processor family | Intel Xeon Silver |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Hexa-channel |
| Memory clock speeds supported by processor | 2400 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Maximum internal memory supported by processor | 1.02 TB |
| Graphics | |
|---|---|
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card | No |
| Features | |
|---|---|
| Scalability | 2S |
| Embedded options available | Yes |
| PCI Express CEM revision | 3.0 |
| Supported instruction sets | AVX, AVX 2.0, AVX-512, SSE4.2 |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 48 |
| Market segment | Server |
| Execute Disable Bit | Yes |
| Processor special features | |
|---|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 1 |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Optane™ DC Persistent Memory Supported | No |
| Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) | No |
| Intel® Speed Select technology - Performance Profile (Intel® SST-PP) | No |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel® Run Sure Technology | No |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Operational conditions | |
|---|---|
| Tcase | 84 °C |
