Cisco Intel Xeon Gold 6342 processor 2.8 GHz 36 MB
Cisco Intel Xeon Gold 6342 processor 2.8 GHz 36 MB

Cisco Intel Xeon Gold 6342 processor 2.8 GHz 36 MB

Cisco · MPN: UCSX-CPU-I6342=
£5,230.99
inc. VAT
Spread the cost with Klarna, Float or SnapFrom 3 interest-free payments of £1,743.66 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview
  • Intel® Xeon® Gold 6342 2.8 GHz
  • 36 MB LGA 4189
  • Processor cores: 24 10 nm 64-bit 230 W
  • Maximum internal memory supported by processor: 6 TB DDR4-SDRAM

The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.

Specifications

Processor

Processor codenameIce Lake
Bus typeUPI
Thermal Design Power (TDP)230 W
Processor cache36 MB
Low priority core frequency2.6 GHz
Low priority cores12
High priority core frequency2.9 GHz
High priority cores12
Processor boost frequency3.5 GHz
Processor operating modes64-bit
System bus rate11.2 GT/s
Processor threads48
Processor seriesIntel Xeon Gold 6000 Series
Processor lithography10 nm
Processor socketLGA 4189
Processor cores24
Processor base frequency2.8 GHz
Processor model6342
Processor generation3rd Generation Intel® Xeon® Scalable
Processor familyIntel® Xeon® Gold
Processor manufacturerIntel

Memory

ECCYes
Memory channelsOcta-channel
Memory clock speeds supported by processor3200 MHz
Memory types supported by processorDDR4-SDRAM
Maximum internal memory supported by processor6 TB
Show all 62 specificationsShow fewer specifications

Graphics

Discrete graphics card modelNot available
On-board graphics card modelNot available
On-board graphics cardNo
Discrete graphics cardNo

Features

Scalability2S
Supported instruction setsAVX, AVX 2.0, AVX-512, SSE4.2
PCI Express slots version4.0
Maximum number of PCI Express lanes64
Market segmentServer
Execute Disable BitYes

Processor special features

Intel® Speed Select Technology – Turbo FrequencyYes
Intel® Speed Select Technology – Core PowerYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Software Guard Extensions (Intel SGX)Yes
Intel 64Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
AVX-512 Fused Multiply-Add (FMA) units2
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Resource Director Technology (Intel® RDT)Yes
Intel® Volume Management Device (VMD)Yes
Mode-based Execute Control (MBE)Yes
Intel® Optane™ DC Persistent Memory SupportedYes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)Yes
Intel® Run Sure TechnologyYes
Intel® Crypto AccelerationYes
Intel® Platform Firmware Resilience SupportYes
Maximum Enclave Size Support for Intel® SGX64 GB
Intel® Total Memory EncryptionYes
Intel® Transactional Synchronization ExtensionsYes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology2.0
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel Trusted Execution TechnologyYes
Intel® Speed Shift TechnologyYes

Operational conditions

Tcase81 °C
